NBB2-8GM50-E2
Pepperl Fuchs Inductive Proximity Sensors: NBB2-8GM50-E2
Housing DiameterΒ Β Β : 08 mm
Sensing DistanceΒ Β Β : 2mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β Β : PBT
Housing MaterialΒ Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Cable PVC , 2 m
Switching Frequency : 0 … 6000 Hz
.
NBB4-12GM50-E2
P&F Inductive Proximity Sensors: NBB4-12GM50-E2
Housing DiameterΒ Β Β : 12 mm
Sensing DistanceΒ Β Β : 4mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β Β : PBT
Housing MaterialΒ Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Cable PVC , 2 m
Switching Frequency : 0 … 800 Hz
.
NBB4-12GM50-E2-V1
Pepperl Fuchs Proximity Sensors: NBB4-12GM50-E2-V1
Housing DiameterΒ Β Β : 12 mm
Sensing DistanceΒ Β Β : 4mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β Β : PBT
Housing MaterialΒ Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Connector plug M12 x 1 , 4-pin
Switching Frequency : 0 … 800 Hz
.
NBB5-18GM50-E2
Pepperl+Fuchs Proximity Sensors: NBB5-18GM50-E2
Housing DiameterΒ Β Β : 18mm
Sensing DistanceΒ Β Β : 5mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β Β : PBT
Housing MaterialΒ Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Cable PVC , 2 m
Switching Frequency : 0 … 800 Hz
.
NBB5-18GM50-E2-V1
Pepperl Fuchs Proximity Sensor: NBB5-18GM50-E2-V1
Housing DiameterΒ Β Β : 18mm
Sensing DistanceΒ Β Β : 5mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β Β : PBT
Housing MaterialΒ Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Connector plug M12 x 1 , 4-pin
Switching Frequency : 0 … 800 Hz
.
NBB8-18GM50-E2
P&F Proximity Sensor: NBB8-18GM50-E2
Housing DiameterΒ Β Β : 18mm
Sensing DistanceΒ Β Β : 8mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β Β : PBT
Housing MaterialΒ Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Cable PVC, 2 m
Switching Frequency : 0 … 500 Hz
.
NBN3-8GM50-E2
Pepperl Fuchs Inductive Sensors: NBN3-8GM50-E2
Housing DiameterΒ Β Β : 08mm
Sensing DistanceΒ Β Β : 3mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Non-Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β Β : LCP
Housing MaterialΒ Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Cable PVC, 2 m
Switching Frequency : 0 … 4500 Hz
.
NBN8-12GM50-E2
Pepperl Fuchs Proximity Switch: NBN8-12GM50-E2
Housing DiameterΒ Β Β : 12mm
Sensing DistanceΒ Β Β : 8mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Non-Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β Β : PBT
Housing MaterialΒ Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Cable PVC, 2 m
Switching Frequency : 0 … 1500 Hz
.
NBN4-12GM50-E2-V1
Pepperl And Fuchs Proximity Switch: NBN4-12GM50-E2-V1
Housing DiameterΒ Β Β : 12mm
Sensing DistanceΒ Β Β : 04mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Non-Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β Β : PBT
Housing MaterialΒ Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Connector M12 x 1, 4-pin
Switching Frequency : 0 … 1200 Hz
.
NBN8-18GM50-E2-V1
P&F Inductive Proximity Sensor: NBN8-18GM50-E2-V1
Housing DiameterΒ Β Β : 18mm
Sensing DistanceΒ Β Β : 08mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Non-Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β Β : PBT
Housing MaterialΒ Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Connector M12 x 1, 4-pin
Switching Frequency : 0 … 500 Hz
.
NBN8-18GM50-E2
Pepperl Fuchs Inductive Proximity Sensor: NBN8-18GM50-E2
Housing DiameterΒ Β Β : 18mm
Sensing DistanceΒ Β Β : 08mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Non-Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β Β : PBT
Housing MaterialΒ Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Cable PVC, 2 m
Switching Frequency : 0 … 500 Hz
.
V1-G-2M-PVC
Pepperl Fuchs Sensor Cables: V1-G-2M-PVC
Connection TypeΒ Β Β Β : Female M12 Connector
StyleΒ Β Β Β Β Β Β Β Β Β Β Β Β : Straight
LockingΒ Β Β Β Β Β Β Β Β Β Β : Screw Connection
Number of pinsΒ Β Β Β Β : 4 Pin
Degree of Protection : IP67 / IP68 / IP69
Number of CoresΒ Β Β Β : 4
Cable LengthΒ Β Β Β Β Β Β : 2 m
Sheathing & Core insulation: PVC
Β
.
V1-G-2M-PUR
Pepperl Fuchs Sensor Cables: V1-G-2M-PUR
Connection TypeΒ Β Β Β : Female M12 Connector
StyleΒ Β Β Β Β Β Β Β Β Β Β Β Β : Straight
LockingΒ Β Β Β Β Β Β Β Β Β Β : Screw Connection
Number of pinsΒ Β Β Β Β : 4 Pin
Degree of Protection : IP67 / IP68 / IP69
Number of CoresΒ Β Β Β : 4
Cable LengthΒ Β Β Β Β Β Β : 2 m
Sheathing & Core insulation: PUR
.
ML100-8-1000-RT/103/115
Pepperl Fuchs Diffuse Photo Sensors: ML100-8-1000-RT/103/115
Detection rangeΒ Β Β : 0 … 1000 mm
Light SourceΒ Β Β Β Β Β : LED
Light TypeΒ Β Β Β Β Β Β Β : modulated visible red light
Control ElementsΒ Β : Light-on/dark-on changeover switch
Operating VoltageΒ Β : 10 … 30 V DC
Signal OutputΒ Β Β Β Β : 1 PNP output, short-circuit protected, reverse polarity protected, open collector
Switching TypeΒ Β Β Β : The switching type of the sensor is adjustable. The default setting is: light-on
Switching Frequency: 1000 Hz
Response TimeΒ Β Β Β : 0.5 ms
DimensionsΒ Β Β Β Β Β Β : W 11mm x H 31 mm x D 20 mm
Degree of protection: IP67
ConnectionΒ Β Β Β Β Β Β :Β 2 m fixed cable
Housing MaterialΒ Β : PC (Polycarbonate)
Cable LengthΒ Β Β Β Β : 2 m
.
ML100-8-H-350-RT/103/115
Pepperl Fuchs BGS Photoelectric Sensor: ML100-8-H-350-RT/103/115
Detection rangeΒ Β Β : 5 … 350 mm
Light SourceΒ Β Β Β Β Β : LED
Light TypeΒ Β Β Β Β Β Β Β : modulated visible red light
Control ElementsΒ Β : Light-on/dark-on changeover switch
Operating VoltageΒ Β : 10 … 30 V DC
Signal OutputΒ Β Β Β Β : 1 PNP output, short-circuit protected, reverse polarity protected, open collector
Switching TypeΒ Β Β Β : The switching type of the sensor is adjustable. The default setting is: light-on
Switching Frequency: 500 Hz
Response TimeΒ Β Β Β : 1 ms
DimensionsΒ Β Β Β Β Β Β : W 11mm x H 31 mm x D 20 mm
Degree of protection: IP67
ConnectionΒ Β Β Β Β Β Β :Β 2 m fixed cable
Housing MaterialΒ Β : PC (Polycarbonate)
Cable LengthΒ Β Β Β Β : 2 m
.
GLV18-8-450/115/120
Pepperl Fuchs Cylindrical Diffuse Sensors: GLV18-8-450/115/120
Housing DiameterΒ Β : 18mm
Detection rangeΒ Β Β : 50 … 450 mm adjustable
Light SourceΒ Β Β Β Β Β : LED
Light TypeΒ Β Β Β Β Β Β Β : Modulated visible red light, 640 nm
Control ElementsΒ Β : Sensitivity Adjustment
Operating VoltageΒ Β : 10 … 30 V DC
Signal OutputΒ Β Β Β Β : 2 PNP, complementary, short-circuit protected, open collectors
Switching TypeΒ Β Β Β : Light/Dark on
Switching Frequency: 500 Hz
Response TimeΒ Β Β Β : β€ 1 ms
Degree of protection: IP67
ConnectionΒ Β Β Β Β Β Β :Β 2 m fixed cable
Housing MaterialΒ Β Β : Plastic housing
Cable LengthΒ Β Β Β Β : 2 m
M100/MV100-RT/76a/103/115
Pepperl Fuchs Thru-beam Sensors: M100/MV100-RT/76a/103/115
Detection rangeΒ Β Β : 0 … 10 m
Light SourceΒ Β Β Β Β Β : LED
Light TypeΒ Β Β Β Β Β Β Β : modulated visible red light
Control ElementsΒ Β : Light-on/dark-on changeover switch
Operating VoltageΒ Β : 10 … 30 V DC
Signal OutputΒ Β Β Β Β : 1 PNP output, short-circuit protected, reverse polarity protected, open collector
Switching TypeΒ Β Β Β : The switching type of the sensor is adjustable. The default setting is: light-on
Switching Frequency: 1000 Hz
Response TimeΒ Β Β Β : 0.5 ms
DimensionsΒ Β Β Β Β Β Β : W 11mm x H 31 mm x D 20 mm
Degree of protection: IP67
ConnectionΒ Β Β Β Β Β Β :Β 2 m fixed cable
Housing MaterialΒ Β : PC (Polycarbonate)
Cable LengthΒ Β Β Β Β : 2 m
ML100-55/103/115
Pepperl Fuchs Retroreflective Sensors: ML100-55/103/115
Detection rangeΒ Β Β : 0 … 5 m
Light SourceΒ Β Β Β Β Β : LED
Light TypeΒ Β Β Β Β Β Β Β : modulated visible red light
Control ElementsΒ Β : Light-on/dark-on changeover switch
Operating VoltageΒ Β : 10 … 30 V DC
Signal OutputΒ Β Β Β Β : 1 PNP output, short-circuit protected, reverse polarity protected, open collector
Switching TypeΒ Β Β Β : The switching type of the sensor is adjustable. The default setting is: light-on
Switching Frequency: 1000 Hz
Response TimeΒ Β Β Β : 0.5 ms
DimensionsΒ Β Β Β Β Β Β : W 11mm x H 31 mm x D 20 mm
Degree of protection: IP67
ConnectionΒ Β Β Β Β Β Β :Β 2 m fixed cable
Housing MaterialΒ Β : PC (Polycarbonate)
Cable LengthΒ Β Β Β Β : 2 m
.
V31-WM-2M-PVC
Pepperl Fuchs Sensor Cables: V31-WM-2M-PVC
Connection TypeΒ Β Β Β : Female M8 Connector
StyleΒ Β Β Β Β Β Β Β Β Β Β Β Β : Angled
LockingΒ Β Β Β Β Β Β Β Β Β Β : Screw Connection
Number of pinsΒ Β Β Β Β : 4 Pin
Degree of Protection : IP67 / IP68 / IP69
Number of CoresΒ Β Β Β : 4
Cable LengthΒ Β Β Β Β Β Β : 2 m
Sheathing & Core insulation: PVC
OBT300-R100-2EP-IO-V31-L
Pepperl Fuchs Triangulation sensor (BGS): OBT300-R100-2EP-IO-V31-L
- Miniature design with versatile mounting options.
- DuraBeam Laser Sensors – durable and employable like an LED.
- Extended temperature range -40 Β°C … 60 Β°C.
- The high degree of protection IP69K.
- IO-Link interface for service and process data.
Detection rangeΒ Β Β : 7 … 300 mm
Light SourceΒ Β Β Β Β Β : Laser Diode
Control ElementsΒ Β : Light-on/dark-on changeover switch
Signal OutputΒ Β Β Β Β : 2 push-pull (4 in 1) outputs,
Switching TypeΒ Β Β Β : The switching type of the sensor is adjustable.
Switching Frequency: 1650 Hz
DimensionsΒ Β Β Β Β Β Β : W 11mm x H 44.5 mm x D 21.5 mm
ConnectionΒ Β Β Β Β Β Β : M8 x 1 connector, 4-pin
V1-G-BK
Pepperl Fuchs Female Cordset, Field Attachable: V1-G-BK
Number of CoresΒ Β Β Β : 4
Connection TypeΒ Β Β Β : Female M12 Connector
StyleΒ Β Β Β Β Β Β Β Β Β Β Β Β : Straight
LockingΒ Β Β Β Β Β Β Β Β Β Β : Screw Connection
Cable Sheath diaΒ Β Β : 4 … 6 mm
NBB8-18GM50-E2-V1
Pepperl Fuchs Inductive Proximity Sensors: NBB8-18GM50-E2-V1
Housing DiameterΒ Β Β : 18 mm
Sensing DistanceΒ Β Β : 8mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β : PBT
Housing MaterialΒ Β Β Β : Brass , White bronze coated
Connection TypeΒ Β Β Β : Connector plug M12 x 1 , 4-pin
Switching Frequency : 0 … 500 Hz
V1-W-2M-PVC
Pepperl Fuchs Sensor Female Cordset: V1-W-2M-PVC
Β
Connection TypeΒ Β Β Β : Female M812 Connector
StyleΒ Β Β Β Β Β Β Β Β Β Β Β Β : Angled
LockingΒ Β Β Β Β Β Β Β Β Β Β : Screw Connection
Number of pinsΒ Β Β Β Β : 4 Pin
Degree of Protection : IP67 / IP68 / IP69
Number of CoresΒ Β Β Β : 4
Cable LengthΒ Β Β Β Β Β Β : 2 m
Sheathing & Core insulation: PVC
GLV18-55/115/120
Pepperl Fuchs Retroreflective Sensors: GLV18-55/115/120
Β
Housing DiameterΒ Β : 18mm
Detection rangeΒ Β Β : 0 … 4 m
Light SourceΒ Β Β Β Β Β : LED
Light TypeΒ Β Β Β Β Β Β Β : Modulated visible red light, 640 nm
Operating VoltageΒ Β : 10 β¦ 30 V DC
Signal OutputΒ Β Β Β Β : 2 PNP, complementary, short-circuit protected, open collectors
Switching TypeΒ Β Β Β : Light/Dark on
Switching Frequency: 500 Hz
Response TimeΒ Β Β Β : β€ 1 ms
Degree of protection: IP67
ConnectionΒ Β Β Β Β Β Β :Β 2 m fixed cable
Housing MaterialΒ Β Β : Plastic housing
Cable LengthΒ Β Β Β Β : 2 m
REF-H60x50
Pepperl Fuchs Reflectors: REF-H60x50
Construction Type Β Β Β : Rectangular
Ambient Temperature : -20 … 60 Β°C (-4 … 140 Β°F)
Material Β Β Β Β Β Β Β Β Β Β Β : PMMA/ABS
DimensionsΒ Β Β Β Β Β Β Β Β : 60 mm x 40.5 mm x 7.5 mm
MountingΒ Β Β Β Β Β Β Β Β Β Β : Mounting holes
OBS4000-18GM60-E5-V1
Pepperl Fuchs Retroreflective Sensors: OBS4000-18GM60-E5-V1
Β
Housing DiameterΒ Β : 18mm
Detection RangeΒ Β Β : 0 β¦ 4 m
Reference TargetΒ Β : H50 reflector
Light SourceΒ Β Β Β Β Β : LED
Light TypeΒ Β Β Β Β Β Β Β : Modulated visible red light, 660 nm
Operating VoltageΒ Β : 10 β¦ 30 V DC
Signal OutputΒ Β Β Β Β : 1 PNP Output,
Switching TypeΒ Β Β Β : Light/dark on electrically switchable
Switching Frequency: 500 Hz
Response TimeΒ Β Β Β :Β 1 ms
Degree of protection: IP67
ConnectionΒ Β Β Β Β Β Β : 4-pin, M12 x 1 connector
Housing MaterialΒ Β Β : Brass, nickel-plated
Β
NBB5-18GM40-Z0
Pepperl Fuchs Inductive Proximity Sensors: NBB5-18GM40-Z0
Housing DiameterΒ Β Β : 18 mm
Sensing DistanceΒ Β Β : 5 mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : 2 Wire
InstallationΒ Β Β Β Β Β Β Β : Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β : PBT
Housing MaterialΒ Β Β Β : Brass, Nickel-plated
Connection TypeΒ Β Β Β : Cable PVC, 2 m
Switching Frequency : 0 β¦ 500 Hz
CBB8-18GS75-E2-V1
Pepperl Fuchs Capacitive Proximity Sensors: CBB8-18GS75-E2-V1
Β
Housing DiameterΒ Β Β : 18 mm
Sensing DistanceΒ Β Β : 1 … 8 mm
Switching FunctionΒ Β : Normally open (NO)
Output typeΒ Β Β Β Β Β Β Β : PNP & 3 Wire
InstallationΒ Β Β Β Β Β Β Β : Flush
Degree of Protection : IP67
Sensing FaceΒ Β Β Β Β Β : PBT
Housing MaterialΒ Β Β Β : Stainless Steel
Connection TypeΒ Β Β Β : Connector plug M12 x 1 , 4-pin
Switching Frequency : 0 β¦ 100 Hz
OBT30-R2F-E2
Pepperl Fuchs Triangulation Sensors(BGS): OBT30-R2F-E2
Detection rangeΒ Β Β : 0 … 30 mm
Reference TargetΒ Β : Standard white, 100 mm x 100 mm
Light SourceΒ Β Β Β Β Β : LED
Light TypeΒ Β Β Β Β Β Β Β : Modulated visible red light , 630 nm
Operating VoltageΒ Β : 10 … 30 V DC
Signal OutputΒ Β Β Β Β : 1 PNP output,
Switching TypeΒ Β Β Β : NO contact / light on
Switching Frequency: 1 kHz
Response TimeΒ Β Β Β : 3500 Β΅s
DimensionsΒ Β Β Β Β Β Β : W 12mm x H 25.5 mm x D 4.1 mm
Degree of protection: IP67
ConnectionΒ Β Β Β Β Β Β : 2 m fixed cable
V31 GM
Pepperl Fuchs Female Cordset, Field Attachable: V31-GM
Operating VoltageΒ Β : max. 30 V DC
Operating currentΒ Β : max. 4 A
Volume resistance : < 3 mΞ©
Ambient temperature : -25 … 85 Β°C (-13 … 185 Β°F)
Pollution degreeΒ Β Β Β : 3
Degree of protection: IP67
ConnectionΒ Β Β Β Β Β Β : 1 x M8 socket, straight
Screw terminals for 0.14 … 0.5 mm2
Screw terminals for 0.14 … 0.5 mm2
V1S-G-BK
Pepperl Fuchs Male Connector, Field-Attachable: V1S-G-BK
Operating voltageΒ Β Β Β Β :Β Β max. 250 V AC/DC
Operating currentΒ Β Β Β Β : max. 4 A
Insulation resistanceΒ Β : min. 100 MΞ©
Plug connectionΒ Β Β Β Β Β : connector M12 x 1 : IEC 61076-2-101
Ambient temperatureΒ Β : -40 … 85 Β°C (-40 … 185 Β°F)
Pollution degreeΒ Β Β Β Β : 3
Screw connectionΒ Β Β Β : CuZn, nickel-plated
BodyΒ Β Β Β Β Β Β Β Β Β Β Β Β Β : PA, black
Degree of protectionΒ Β : EN 60529
V31S GM
Pepperl Fuchs Field-Attachable Male Connector: V31S-GM
Operating VoltageΒ : max. 70 V DC
Operating currentΒ Β : max. 4 A
Volume resistance : < 3 mΞ©
Ambient temperature : -40 … 85 Β°C (-40 … 185 Β°F)
Pollution degreeΒ Β Β Β : 3
Degree of protection : IP67
ConnectionΒ Β Β Β Β Β Β : 1 x M8 straight connector Screw terminals for 0.14 … 0.5 mm2
