Omron S8VK-WA48024 Power Supply
The Omron S8VK-WA48024 Power Supply provides a 480 W power rating, 24 VDC output voltage, and 20 A rated current. This durable SMPS Power Supply is suitable for DIN rail mounting and comes with Push-In Plus Terminal to enable easy wiring and dependable connectivity. Built for 200 to 240 VAC(Three-phase/single-phase/two-phase) input at 50/60 Hz frequency, it maintains stable DC performance and includes protection features against overload, overvoltage, and short-circuit conditions. Manufactured by Omron, this model is part of the Omron Power Supply series of Switch Mode Power Supplies, available under the Omron S8VK Series.
| Brand | Omron |
| Product Type | SMPS |
| Model Number | S8VK-WA48024 |
Omron S8VK-WA48024 Power Supply - Technical Specifications
| Specification | Value |
|---|---|
| Power rating | 480 W |
| Output voltage | 24 VDC |
| Connection | Terminal blocks |
| Terminal type | Push-In Plus Terminal |
| Mounting | DIN rail |
| Efficiency | 94 % typ.(at three-phase 200 VAC input) 93 % typ.(Single-phase/two-phase 200 VAC input Single-phase/two-phase 200 VAC input) 94 % typ.(at three-phase 230 VAC input) 94 % typ.(Single-phase/two-phase 230 VAC input) |
| Rated input voltage | 200 to 240 VAC(Three-phase/single-phase/two-phase) |
| Input Frequency | 50/60 Hz |
| Rated input current | 1.6 A typ.(at three-phase 200 VAC input) 2.6 A typ.(Single-phase/two-phase 200 VAC input Single-phase/two-phase 200 VAC input) 1.4 A typ.(at three-phase 230 VAC input) 2.3 A typ.(Single-phase/two-phase 230 VAC input) |
| Input Leakage current | 1.0 mA max.(at three-phase 200 VAC input) 1.0 mA max.(at three-phase 230 VAC input) |
| Rated output current | 20 A |
| Output voltage variable range | 24 to 29.5 V (with V.ADJ) |
| Start-up time | 1000 ms max.(at three-phase 200 VAC input) 1000 ms max.(at three-phase 230 VAC input) |
| Hold time | 30 ms typ.(at three-phase 200 VAC input) 30 ms typ.(at three-phase 230 VAC input) |
| Output indicator | Yes (LED: Green) |
| Vibration resistance | 10 to 55 Hz, maximum 5 G, 0.42 mm single amplitude for 2 h each in X, Y, and Z directions |
| Shock resistance | 150 m/s2, in each 6 directions 3 times |
| Ambient temperature (Operating) | β40 to 70Β°C |
| Ambient temperature (Storage) | β40 to 85Β°C |
| Ambient humidity (OperatingStorage) | 95% max. (Storage humidity: 95% max.) |
| Cooling fan | No |
| Degree of protection | IP20 by EN/IEC 60529 |
| Weight | 1050 g max. |
The Omron S8VK-WA48024 is frequently assessed alongside related units in the Omron Switch Mode Power Supply range, as these SMPS models share comparable wiring behaviour, thermal characteristics, load endurance, and panel integration features. Engineers often evaluate related models such as Omron S8VK-X09024-EIP (90 W, 24 VDC, 3.75 A, DIN rail), Omron S8VK-G48048 (480 W, 48 VDC, 10 A, DIN rail), and Omron S8VK-X48024A-EIP (480 W, 24 VDC, 20 A, DIN rail) when configuring power rails for PLC racks, servo drives, motion assemblies, and distributed I/O terminals. Comparing specifications like power rating, output voltage behaviour, continuous output current, and mounting orientation helps maintain predictable voltage delivery across machinery with dynamic load patterns. The S8VK-WA48024 fits smoothly into conveyors, dosing modules, electrical frames, and compact control panels where a dependable Omron SMPS Power Supply is required. These related SMPS variants also support unified wiring layouts, easier spare handling, and consistent power distribution across multi-panel automation systems.
