Omron S8VK-S03024 Power Supply
Omron S8VK-S03024 SMPS is a 30 W switch mode power supply designed to provide 24 VDC with 1.3 A rated output current. It supports single-phase 85 to 264 VAC or 90 to 350 VDC input, together with the specified 265 to 300 VAC range, at 50/60 Hz. DIN rail mounting supports panel installation, while push-in terminals and terminal blocks provide the electrical connection arrangement. Typical efficiency is specified at 87% with 115 VAC input and 86% with 230 VAC input. A green LED provides output-status indication, and the enclosure carries an IP20 rating. Within the S8VK-S Series, the S8VK-S03024 provides a 30 W, 24 VDC configuration. Compare other 30W 24V power supplies from Omron industrial controls.

| Brand | Omron |
| Product | Power Supply |
| Model Number | S8VK-S03024 |
Omron S8VK-S03024 Power Supply - Technical Specifications
| Specification | Value |
|---|---|
| Power rating | 30 W |
| Output voltage | 24 VDC |
| Rated output current | 1.3 A |
| Terminal type | Push-in Terminal |
| Mounting method | DIN rail |
| Connection | Terminal blocks |
| Efficiency | 87% typ. (at 115 VAC input) 86% typ. (at 230 VAC input) |
| Rated input voltage | Single-phase, 85 to 264 VAC, 90 to 350 VDC , 265 to 300 VAC |
| Rated input current | 0.58 A typ. (at 115 VAC input) 0.36 A typ. (at 230 VAC input) |
| Input Leakage current | 0.5 mA typ. (at 115 VAC input) 1 mA typ. (at 230 VAC input) |
| Input Frequency | 50/60 Hz |
| Output indicator | Yes (LED: Green) |
| Output voltage variable range | ?10% to 15% (with V. ADJ) |
| Start-up time | 1000 ms typ. (at 115 VAC input) 1000 ms typ. (at 230 VAC input) |
| Hold time | 30 ms typ. (at 115 VAC input) 140 ms typ. (at 230 VAC input) |
| Vibration resistance | 10 to 55 Hz, maximum 5 G, 0.42 mm single amplitude for 2 h each in X, Y, and Z directions |
| Shock resistance | 150 m/s2, in each 6 directions 3 times |
| Ambient temperature (Operating) | ?40 to 70°C |
| Ambient temperature (Storage) | ?40 to 85°C |
| Ambient humidity (OperatingStorage) | 95% max. (Storage humidity: 95% max.) |
| Cooling fan | No |
| Degree of protection | IP20 by EN/IEC 60529 |
| Weight | 250 g max. |
The Omron S8VK-S03024 Power Supply provides 30 W rated power with a 24 VDC output and 1.3 A rated current. It supports single-phase 85 to 264 VAC or 90 to 350 VDC input, together with the specified 265 to 300 VAC range, at 50/60 Hz. DIN rail mounting and push-in terminals provide the installation and wiring arrangement, while terminal blocks organize the electrical connection points. Typical efficiency is specified at 87% with 115 VAC input and 86% with 230 VAC input. A green LED provides output-status indication, and the enclosure carries an IP20 protection rating. These values define a lower-power 24 VDC configuration where the connected load should remain within the rated 1.3 A output. Source compatibility, available DIN rail space, push-in terminal access, output voltage, and current demand should all be verified before installation. Models in the same 24 VDC voltage class can differ significantly in rated current as power capacity increases. Comparing equal-voltage models is therefore useful for determining whether additional current is required without changing the downstream voltage requirement. For a 480 W DIN rail model that maintains 24 VDC while increasing rated output current to 20 A, compare the Omron S8VK-WB48024.
