Omron S8VK-T12024 Power Supply

Omron S8VK-T12024 SMPS is a 120 W switch mode power supply designed to provide 24 VDC with 5 A rated output current from higher-voltage industrial input systems. It accepts 380 to 480 VAC using three-phase or two-phase input and also supports 450 to 600 VDC at 50/60 Hz. DIN track mounting with rod terminals and terminal blocks provides the installation and wiring arrangement. Typical efficiency is specified at 89% with three-phase 400 VAC input. A green LED provides output-status indication, and the enclosure carries an IP20 protection rating. Within the S8VK-T Series, the S8VK-T12024 provides a 120 W, 24 VDC configuration. Compare other three-phase industrial power supplies from Omron control solutions.

Omron S8VK-T12024 Power Supply
BrandOmron
ProductPower Supply
Model NumberS8VK-T12024

Omron S8VK-T12024 Power Supply – Technical Specifications

SpecificationValue
Power rating120 W
Output voltage24 VDC
Rated output current5 A
Terminal typeRod terminal
Mounting methodDIN track mounting
ConstructionCovered type
ConnectionTerminal blocks
Efficiency89% typ. (Three-phase 400 VAC input)
Rated input voltage380 to 480 VAC (Three-phase / two-phase)450 to 600 VDC
Rated input current0.40 A typ. (Three-phase 400 VAC input)
Input Leakage current3.5 mA max., 0.70 mA typ. (Three-phase 400 VAC input)
Input Frequency50/60Hz (47 to 63 Hz)
Output indicatorYes (LED, color: green, lighting from 80 to 90% or more of rated voltage)
Output voltage variable range24 to 29.5 VDC With V.ADJ
Maximum peak current6 A
Start-up time600 ms typ. (Three-phase 400 VAC input)
Hold time35 ms typ. (Three-phase 400 VAC input)
Vibration resistance10 to 55 Hz, 0.375 mm Single amplitude in every 3 directions for 2 hours
Shock resistance150 m/s2, in each 6 directions 3 times
Ambient temperature (Operating)-40 to 70 ? (with no freezing or condensation)
Ambient temperature (Storage)-40 to 85 ? (with no freezing or condensation)
Ambient humidity (OperatingStorage)95% max.
Degree of protectionIP20, EN/IEC 60529
Weight (Main)850 g max.

The Omron S8VK-T12024 Power Supply provides 120 W rated power with a 24 VDC output and 5 A rated current. It accepts 380 to 480 VAC using three-phase or two-phase input and also supports 450 to 600 VDC at 50/60 Hz. DIN track mounting with rod terminals and terminal blocks provides the installation and electrical connection arrangement. Typical efficiency is specified at 89% with three-phase 400 VAC input, and a green LED provides output-status indication. The enclosure carries an IP20 protection rating. Its higher-voltage input architecture is an important difference from single-phase S8VK models, so the available incoming supply should be confirmed before comparing output capacity. Connected equipment should require 24 VDC and keep combined current demand within the rated 5 A output. Input phase, voltage range, output voltage, output current, rated power, mounting format, and terminal type should all be evaluated during model selection. A different S8VK product may provide the same 120 W, 24 VDC, and 5 A output while accepting a completely different incoming source, meaning equal output ratings do not make the models interchangeable on the input side. For a 120 W 24 VDC model rated at 5 A from another S8VK configuration, compare the Omron S8VK-C12024.
