Omron S8JX-P60024N Power Supply
The Omron S8JX-P60024N Power Supply offers 600 W power rating, 24 VDC output voltage, and 27 A rated current. This SMPS Power Supply is designed for Front mounting installation and features Screw Terminal for reliable electrical connections. Operating on 100 to 240 VAC input at 50/60Hz frequency, with extended DC input range (80β370 VDC), it ensures stable output with power factor correction and EMI Class B compliance. Enhanced with remote sensing, alarm output, and parallel or series operation support, itβs ideal for industrial automation panels. Manufactured by Omron, part of the Omron Power Supply range of Switch Mode Power Supplies, available under the Omron S8JX-P Series.
| Brand | Omron |
| Product Type | SMPS |
| Model Number | S8JX-P60024N |
Omron S8JX-P60024N Power Supply - Technical Specifications
| Specification | Value |
|---|---|
| Power rating | 600 W |
| Output voltage | 24 VDC |
| Connection | Terminal blocks |
| Terminal type | Screw Terminal |
| Mounting | Front mounting |
| Efficiency | 78% typ. (at 100 VAC input) 78% typ. (at 200 VAC input) |
| Rated input voltage | 100 to 240 VAC |
| Input Frequency | 50/60Hz |
| Rated input current | 8.7 A max. (at 100 VAC input) 4.3 A max. (at 200 VAC input) |
| Input Leakage current | 0.5 mA max. (at 100 VAC input) 1.0 mA max. (at 200 VAC input) |
| Rated output current | 27 A |
| Output voltage variable range | -10 to +15% With V.ADJ |
| Start-up time | 1000 ms typ. (at 100 VAC input) 1000 ms typ. (at 200 VAC input) |
| Hold time | 20 ms min. (at 100 VAC input) 20 ms min. (at 200 VAC input) |
| Output indicator | Yes (color: green) |
| Vibration resistance | 10 to 55 Hz, 0.375 mm single amplitude in each 3 directions for 2 hours |
| Shock resistance | 150 m/s2, in each 6 directions 3 times |
| Ambient temperature (Operating) | -10 to 70 β |
| Ambient temperature (Storage) | -25 to 75 β |
| Ambient humidity (OperatingStorage) | 25 to 85% |
| Cooling fan | Yes |
| Weight | 1800 g max. |
The Omron S8JX-P60024N is frequently evaluated with other models in the Omron Switch Mode Power Supply group, as these SMPS units share similar behaviour in thermal response, wiring layout, load handling, and rated input characteristics. Engineers often compare related models such as Omron S8JX-P30024C (300 W, 24 VDC, 100 to 240 VAC, 14 A, Front mounting), Omron S8JX-P30048CD (300 W, 48 VDC, 100 to 240 VAC, 7 A, DIN rail), and Omron S8JX-P60005CD (600 W, 5 VDC, 100 to 240 VAC, 120 A, DIN rail) when designing power rails for automation cabinets, motion drives, PLC racks, or distributed I/O stations. Analysing differences in power rating, output voltage behaviour, mounting format, rated input voltage, and continuous output current helps ensure voltage stability under diverse machine loads. The S8JX-P60024N integrates smoothly into conveyors, dosing modules, electrical frames, and industrial panels where a dependable Omron SMPS Power Supply is required.
