Omron GLS-1L Magnetic Proximity Sensor
Omron GLS-1L is a magnetic proximity sensor with a 15 mm sensing distance, SPST-NO switching, and a pre-wired connection. Its maximum response frequency is 20 Hz. The specified operating and storage temperature range is -20 to 60°C without icing or condensation, while operating and storage humidity is 35% to 85%. ABS is listed as the construction material, and the enclosure protection rating is IP62. The pre-wired connection is specified without a separate cable-length value. The source does not provide a supply-voltage value, current-consumption value, or separate setting distance for this model. The GLS-1L is listed under magnetic proximity sensors from Omron industrial sensing products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | GLS-1L |
Omron GLS-1L Magnetic Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Magnetic |
| Sensing Distance | 15 mm |
| Contact Circuit | SPST-NO |
| Connection | Pre-wired |
| Response Frequency | 20 Hz max. |
| Ambient Temperature Range | Operating/Storage: −20 to 60°C (with no icing or condensation) |
| Ambient Humidity Range | Operating/storage: 35% to 85% (with no condensation) |
| Material | ABS |
| Degree Of Protection | IP62 |
The Omron GLS-1L Proximity Sensor uses magnetic sensing with a 15 mm sensing distance, SPST-NO switching, and a pre-wired connection. The source specifies a maximum response frequency of 20 Hz. It does not provide a supply-voltage value, current-consumption value, control-output current, standard sensing object, or separate setting-distance value for this model, so those characteristics are not added. ABS is listed as the construction material, and IP62 is the stated protection level. The pre-wired format is part of the model configuration, although no cable-length value is supplied in the row. These details define the documented electrical connection and environmental construction without adding unsupported output specifications.
Operating and storage conditions for the GLS-1L cover -20 to 60°C without icing or condensation, with humidity from 35% to 85%. The magnetic sensing method is paired with SPST-NO switching and the stated 15 mm sensing distance. No response-time value beyond the 20 Hz maximum frequency is provided, and no additional protection circuits are listed in the supplied data. The source also does not state insulation resistance, dielectric strength, vibration resistance, or shock resistance for this model. For another compact Omron proximity sensor using a connector-based cylindrical sensing head and a shorter 0.6 mm sensing distance, see E2NC-EDR6-F.
