Omron E2NC-EDR6-F Proximity Sensor
Omron E2NC-EDR6-F is a smart cylindrical shielded proximity sensor with a 0.6 mm sensing distance and connector connection. Ferrous metal is the specified detectable object, with a 5 × 5 mm standard sensing object. The source lists free cutting for the connection specification and IP67 as the protection level. Operating temperature is 10 to 60°C without icing or condensation, while storage is -10 to 60°C. Operating and storage humidity is 35% to 85%. Brass, heat-resistant ABS, and PES are listed among the construction materials. The compact cylindrical head is intended to be used with the stated connector arrangement. The E2NC-EDR6-F is listed under smart proximity sensors from Omron sensing products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2NC-EDR6-F |
Omron E2NC-EDR6-F Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Cylindrical |
| Sensing Distance | 0.6 mm |
| Connection | Connector |
| Cable Specifications | Free cutting |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | 5 × 5 mm |
| Ambient Temperature Range | Operating:10°C to 60°C (with no icing or condensation) Storage:-10°C to 60°C (with no icing or condensation) |
| Ambient Humidity Range | Operating/storage: 35% to 85% (with no condensation) |
| Material | Brass, Heat-resistant ABS, PES |
| Degree Of Protection | IP67 |
| Weight | Approx. 120 g |
The Omron E2NC-EDR6-F Proximity Sensor uses a smart cylindrical shielded sensing head with a 0.6 mm sensing distance and connector connection. Ferrous metal is the specified detectable object, with a 5 × 5 mm standard sensing object. The source lists the connection specification as free cutting and does not provide an output type, supply voltage, response frequency, or current-consumption value for this sensor-head row. Operating temperature is 10 to 60°C without icing or condensation, while storage is -10 to 60°C. Operating and storage humidity is specified from 35% to 85%. Brass, heat-resistant ABS, and PES are listed as construction materials, and the sensor carries IP67 protection.
For the E2NC-EDR6-F, the documented selection points are the cylindrical form, shielded 0.6 mm sensing distance, connector arrangement, ferrous-metal detection, and 5 × 5 mm standard sensing object. The environmental range is retained exactly as supplied, including the 10°C lower operating limit and -10°C storage limit. No electrical output values are added because they are not present in the supplied row. The source does not state a separate setting distance. IP67 remains the stated degree of protection. For another cylindrical shielded E2NC sensor with connector connection but a longer 1 mm sensing distance, see E2NC-ED01.
