Omron G9SX-NSA222-T03-RT Safety Relay Unit
The Omron G9SX-NSA222-T03-RT Safety Relay Unit provides efficient safety management with 24 VDC operation and β15% to +10% supply tolerance. Offering a fast 30 ms operating time and 10 ms response, it enables quick safety output activation in automated environments. Its rugged design withstands industrial vibration, strong shock, and temperatures between β10 and 55Β°C. Suitable for multi-zone or interconnected safety systems, it supports reliable machine protection. Manufactured by Omron and supplied under Omron Relay, this unit belongs to the G9SX Series.
| Brand | Omron |
| Product Type | Safety Relay Unit |
| Model Number | G9SX-NSA222-T03-RT |
Omron G9SX-NSA222-T03-RT Safety Relay Unit - Technical Specifications
| Specification | Value |
|---|---|
| Rated voltage | 24 VDC |
| Operating voltage range | -15% to +10% of rated supply voltage |
| Power consumption | 2 W max |
| Operating time | 30 ms max |
| Response time | 10 ms max |
| Vibration resistance | Frequency: 10 to 55 to 10 Hz, 0.375-mm single amplitude (0.75-mm double amplitude) |
| Shock resistance | Destruction 300 m/s2 Malfunction 100 m/s2 |
| Ambient operating temperature | β10 to 55Β°C (with no icing or condensation) |
| Ambient operating humidity | 25% to 85% |
| Terminal tightening torque | 0.5 NΒ·m |
| Weight | Approx. 165 g |
With robust functional safety at its core, the G9SX-NSA222-T03-RT from Omron is engineered for precise and reliable signal processing in critical environments. Operating at a rated voltage of 24 VDC, it ensures stable performance with an operating voltage range of -15% to +10% of the rated input. Its low power consumption of 2 W max supports energy-efficient operations while maintaining fast response times of 10 ms and an operating time capped at 30 msβcritical for fast-acting safety systems in manufacturing and machine automation.
This safety relay unit is built to withstand the rigors of harsh industrial conditions, offering vibration resistance across 10 to 55 Hz at 0.75 mm double amplitude, and strong shock resistance of up to 300 m/sΒ². It operates reliably in ambient temperatures ranging from β10Β°C to 55Β°C and humidity levels of 25% to 85%, making it well-suited for India's diverse industrial environments. Its compact size and weight of 165 g, coupled with a terminal tightening torque of 0.5 NΒ·m, simplify installation into tight control panels.
