Omron E3X-MZV11 2M Fiber Optic Sensor

Omron E3X-MZV11 2M is a 2-channel NPN fiber amplifier designed for object detection with dual-output control. Its 2 sensing channels allow optical signals from two fiber sensing points to be processed through one amplifier, while 2 NPN outputs provide corresponding switching signals. Teach-In setup supports sensing adjustment, and selectable Dark-ON and Light-ON modes provide flexible output logic. A 0.1 ms response supports fast detection, while timer and twin-output functions extend control capability. The amplifier uses a 2 m cable, operates from 12 to 24 VDC and uses polarity-free red light. The E3X-MZV11 2M belongs to the E3X-ZV/MZV Series within the fiber amplifier range from Omron sensing products, combining dual-channel sensing with NPN twin outputs.

Omron E3X-MZV11 2M Fiber Optic Sensor
BrandOmron
ProductFiber Amplifier Unit
Model NumberE3X-MZV11 2M

Omron E3X-MZV11 2M Fiber Optic Sensor - Technical Specifications

SpecificationValue
ShapeCuboid, rail mounting
Connection MethodCable
Cable Length2 m
Sensing MethodAmplifier
ApplicationObject detection
Features2 channels, Twin outputs
Setting MethodTeach-In
OutputNPN
Operation ModeDark-ON, Light-ON
Power Supply Voltage12-24 V
FunctionTimer, Twin
Response Time0.1 ms
Material HousingPolycarbonate
Number Of Digital Outputs2
Type Of LightPolarity free red light

The Omron E3X-MZV11 2M Fiber Amplifier uses 2 sensing channels and provides 2 NPN outputs for object detection. Its dual-channel architecture allows two fiber sensing signals to be processed through a single amplifier, while twin outputs provide corresponding switching control. Teach-In setup supports sensing adjustment, and selectable Dark-ON and Light-ON operation allows output logic to match different detection conditions. A 0.1 ms response supports fast signal processing, while the timer provides additional output timing control. The amplifier uses polarity-free red light as its optical source and operates from 12 to 24 VDC. A 2 m cable provides the electrical connection, and the cuboid housing supports rail mounting. Dual-channel sensing, NPN output, twin outputs, Teach-In adjustment and fast response are the primary functional attributes of E3X-MZV11. These characteristics distinguish it from single-channel E3X-ZV variants within the same series grouping. For another supplied dual-channel NPN fiber amplifier providing 2 outputs and the same 0.1 ms response but operating from 10 to 30 VDC with bank and self-diagnosis functions, the E3NX-MA11 2M provides a useful related model for functional comparison.
