Omron E2E-X8MD1S 2M Proximity Sensor
The Omron E2E-X8MD1S 2M Proximity Sensor offers Inductive, M12, Unshielded, 8 mm Sensing distance, PVC (oil-resistant) Cable, Pre-wired 2 M Cable, DC 2-Wire , NO , 12 to 24 VDC Power supply voltage. Manufactured by Omron under the Omron Proximity Sensors category, this model belongs to the Omron E2E Series.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-X8MD1S 2M |
Omron E2E-X8MD1S 2M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M12 |
| Mounting | Unshielded |
| Sensing Distance | 8 mm |
| Setting Distance | 0 to 6.4 mm |
| Output Configuration | DC 2-Wire |
| Operation Mode | NO |
| Connection | Pre-wired 2 M Cable |
| Cable Specifications | PVC (oil-resistant) |
| Differential Travel | 10% max. of sensing distance |
| Detectable Object | Ferrous metal (The sensing distance decreases with non-ferrous metal. Refer to Engineering Data on pages 10 and 11. |
| Standard Sensing Object | Iron, 30 Γ 30 Γ 1 mm |
| Response Frequency | 0.8 kHz |
| Control Output Residual Voltage | 3 V max. (Load current: 100 mA, Cable length: 2 m) |
| Control Output Load Current | 3 to 100 mA, Diagnostic output: 50 mA for -D1(5)S Models |
| Indicator | Red Indicator |
| Protection Circuit | Surge suppressor, Load short-circuit protection (for control and diagnostic output) |
| Ambient Temperature Range | Operating: β25 to 70Β°C, Storage: β40 to 85Β°C (with no icing or condensation) |
| Ambient Humidity Range | Operating/storage: 35% to 95% (with no condensation) |
| Insulation Resistance | Β±15% max. of sensing distance at 23Β°C in the temperature range of β25 to 70Β°C |
| Dielectric Strength | 50 MΞ© min. (at 500 VDC) between current-carrying parts and case |
| Vibration Resistance | Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Voltage Influence | Β±1% max. of sensing distance at rated voltage in the rated voltage Β±15% range |
| Material Case | Stainless steel (SUS303) |
| Material Toothed Washer | Zinc-plated iron |
| Material Sensing Surface | PBT |
| Material Clamping Nut | Nickel-plated brass |
| Degree Of Protection | Pre-wired Models: IEC 60529 IP67, in-house standards: oil-resistant |
| Weight | Approx. 70 g |
The Omron E2E-X8MD1S 2M is often compared with other models in the E2E Proximity Sensor group due to shared installation characteristics and consistent sensing behavior. Engineers frequently evaluate Omron E2E-X5Y2 2M (M18, 5 mm sensing, Shielded, AC 2-Wire, NC, Pre-wired 2 M Cable), Omron E2E-X3D1-M1GJ (M12, 3 mm sensing, Shielded, DC 2-wire, NO, Pre-wired connector), and Omron E2E-X4MD2-M1G (M8, 4 mm sensing, Unshielded, DC 2-wire, NC, M12 Connector) when selecting suitable alternatives. This helps maintain compatibility when matching head size, sensor type, output logic, operation mode, and connection method. The E2E-X8MD1S 2M fits smoothly into machinery, fixtures, conveyors, and automation setups requiring dependable detection from an Omron Proximity Sensor.
