Omron E2E-X5MF1-M1 Proximity Sensor
Omron E2E-X5MF1-M1 delivers a 5 mm sensing distance through an M12 cylindrical unshielded format for non-contact ferrous-metal detection. The sensing range can be set from 0 to 4 mm, while DC 3-wire PNP NO output is provided through an M12 connector. It operates from 12 to 24 VDC and uses an iron 15 × 15 × 1 mm standard sensing object. Response frequency is 0.4 kHz, with control output rated at 200 mA max. A red status indicator is specified along with short-circuit, surge, and reverse-polarity protection. The E2E-X5MF1-M1 belongs to M12 PNP inductive sensors from Omron factory sensing products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-X5MF1-M1 |
Omron E2E-X5MF1-M1 Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Housing Shape | Cylindrical |
| Size | M12 |
| Mounting type | Unshielded |
| Sensing Distance | 5 mm |
| Setting Distance | 0 to 4 mm |
| Output configuration | DC 3-wire PNP |
| Operation Mode | NO |
| Connection Method | M12 Connector |
| Wire color / pin arrangement | 1: +V, 3: 0 V, 4: Control output |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 15 ×15 × 1 mm |
| Response Frequency | 0.4 kHz |
| Power Supply Voltage | 12 to 24 VDC |
| Protection Circuit | Load short-circuit protection, Surge suppressor, Reverse polarity protection |
| Ambient Temperature Range | Operating/Storage: −40 to 85°C (with no icing or condensation) |
| Degree of Protection | IEC 60529 IP67 |
| Control Output | 200 mA max. |
| Indicators | Operation indicator (red) |
| Materials | Nickel-plated brass, PBT, Nickel-plated brass, Zinc-plated iron. |
| Weight | Approx. 25 g |
The Omron E2E-X5MF1-M1 Proximity Sensor uses an M12 cylindrical unshielded sensing arrangement to achieve a 5 mm detection range with a 0 to 4 mm setting distance. DC 3-wire PNP NO switching is provided through an M12 connector, and the operating supply is 12 to 24 VDC. Ferrous metal is the specified detection material, with an iron 15 × 15 × 1 mm standard sensing object. Response frequency is rated at 0.4 kHz, while control output supports 200 mA max. A red indicator shows operation status. Load short-circuit protection, surge suppression, and reverse-polarity protection are included for the electrical circuit.
Operating and storage conditions for the E2E-X5MF1-M1 cover -40 to 85°C without icing or condensation. IEC 60529 IP67 is specified for enclosure protection. The unshielded M12 design provides the stated 5 mm detection clearance, while connector-based wiring makes field cable replacement easier during machine maintenance. Nickel-plated brass, PBT, and zinc-plated iron are listed among the construction materials. PNP NO switching provides a sourcing normally open signal for compatible industrial controllers. For a smaller E2E sensor using an M5 body, 1.2 mm sensing distance, NPN switching, and oil-resistant PVC cabling, see E2E-S05S12-CJ-C1 0.3M.
