Omron E2E-X3D2-M1G Proximity Sensor
Omron E2E-X3D2-M1G offers normally closed DC 2-wire sensing in an M12 short-body design with a 3 mm detection distance. The shielded sensing face supports a 0 to 2.4 mm setting range and connects through an M12 connector. Operating voltage is 12 to 24 VDC, while an iron 12 × 12 × 1 mm object is specified as the standard ferrous target. Response frequency is 1 kHz, and control current ranges from 3 to 100 mA. An orange operation indicator is provided with surge suppression and load short-circuit protection. The E2E-X3D2-M1G is grouped with DC 2-wire NC proximity sensors from Omron industrial sensing technology.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-X3D2-M1G |
Omron E2E-X3D2-M1G Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Inductive |
| Size | M12 |
| Mounting type | Shielded |
| Sensing Distance | 3 mm |
| Setting Distance | 0 to 2.4 mm |
| Output configuration | DC 2-wire |
| Operation Mode | NC |
| Body Length | Short Body |
| Connection Method | M12 Connector |
| Detectable Object | Ferrous metal |
| Standard Sensing Object | Iron, 12 × 12 × 1 mm |
| Response Frequency | 1 kHz |
| Power Supply Voltage | 12 to 24 VDC |
| Protection Circuit | Surge suppressor, Load short-circuit protection |
| Ambient Temperature Range | Operating: -25 to 70°C, Storage: -40 to 85°C (with no icing or condensation) |
| Degree of Protection | IP67 (IEC 60529), IP67G |
| Control Output | 3 to 100 mA Polarity: 3 V max. No polarity: 5 V max. |
| Indicators | Operation indicator (orange) |
| Materials | Nickel-plated brass, Polybutylene terephthalat (PBT), Nickel-plated brass, Zinc-plated iron, Vinyl chloride (PVC). |
| Weight | Approx. 55 g |
The Omron E2E-X3D2-M1G Proximity Sensor provides DC 2-wire NC switching from an M12 shielded short-body sensing arrangement with a 3 mm detection distance and a 0 to 2.4 mm setting range. It operates from 12 to 24 VDC and connects through an M12 connector. Ferrous metal is specified as the detectable target, using an iron 12 × 12 × 1 mm standard sensing object. Response frequency is 1 kHz. Control current ranges from 3 to 100 mA, while an orange operation indicator shows switching status. Surge suppression and load short-circuit protection are specified for the sensor output.
Operating conditions for the E2E-X3D2-M1G extend from -25 to 70°C, while storage covers -40 to 85°C without icing or condensation. IP67 according to IEC 60529 and IP67G are listed. The short M12 housing reduces installation depth, and shielded sensing allows placement close to surrounding metal. Its two-wire NC architecture provides a normally closed interface using fewer conductors than a three-wire sensor. Nickel-plated brass, PBT, zinc-plated iron, and PVC are included among the material specifications. For another E2E NEXT sensor with an 8 mm range, PNP NO output, and Smartclick connection, see E2E-X8MB1DL12-M1TJ 0.3M.
