Omron E2E-C03SR8-WC-B1 2M Proximity Sensor
The Omron E2E-C03SR8-WC-B1 2M Proximity Sensor offers Inductive, 3 dia., Shielded, 0.8 mm Sensing distance, PNP NO Output, PVC (oil-resistant) Cable, Pre Wired, Length 2M, 10 to 30 VDC Power supply voltage. Manufactured by Omron under the Omron Proximity Sensors category, this model belongs to the Omron E2E Small Diameter.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-C03SR8-WC-B1 2M |
Omron E2E-C03SR8-WC-B1 2M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Small-diameter |
| Size | 3 dia. |
| Mounting | Shielded |
| Sensing Distance | 0.8 mm |
| Setting Distance | 0 to 0.56 mm |
| Output Configuration | PNP |
| Operation Mode | NO |
| Connection | Pre Wired, Length 2M |
| Cable Specifications | PVC (oil-resistant) |
| Power Supply Voltage | 10 to 30 VDC |
| Standard Target | Iron, 3 Γ 3 Γ 1 mm |
| Differential Travel | 15% max. of sensing distance |
| Detectable Object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Response Frequency | 5 kHz |
| Current Consumption | 10 mA max |
| Indicator | Operation indicator: Yellow (complies with European standard EN60947-5-2) Lights during output. |
| Protection Circuit | Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, Load short-circuit protection |
| Ambient Temperature Range | Operation and storage: β25 to 70Β°C (with no icing or condensation) |
| Ambient Humidity Range | Operation and storage: 35% to 95% (with no condensation) |
| Insulation Resistance | Β±15% max. of sensing distance at 23Β°C within temperature range of β25 to 70Β°C |
| Dielectric Strength | 50 MΞ© min. (at 500 VDC) between current-carrying parts and case |
| Vibration Resistance | Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Shock Resistance | Destruction: 500 m/s2 10 times each in X, Y, and Z directions |
| Voltage Influence | Β±2.5% max. of sensing distance at rated voltage in the rated voltage Β±15% range |
| Degree Of Protection | IP67 |
| Weight | Approx. 25 g |
The Omron E2E-C03SR8-WC-B1 2M is often compared with other models in the E2E Small-diameter Proximity Sensor group due to shared installation characteristics and consistent sensing behavior. Engineers frequently evaluate Omron E2E-S05S12-WC-C1 2M (M5, 1.2 mm Sensing Distance, NPN, NO, PVC (oil-resistant), Pre Wired, Length 2M), Omron E2E-C05S01-WC-C1 2M (5.4 dia, 1 mm Sensing Distance, NPN, NO, PVC (oil-resistant), Pre Wired, Length 2M), and Omron E2E-S04N02-WC-C1 2M (M4, 2 mm Sensing Distance, NPN, NO, PVC (oil-resistant), Pre Wired, Length 2M) when selecting suitable alternatives. This ensures compatibility when matching size, sensing distance, wiring style, output logic, or connector format. The E2E-C03SR8-WC-B1 2M integrates smoothly into machinery, fixtures, conveyors, and automation systems requiring dependable detection from an Omron Small-diameter Proximity Sensor.
