Omron E2E-S05S12-WC-C1 2M Proximity Sensor
Omron E2E-S05S12-WC-C1 2M uses a compact M5 shielded sensing head with a 1.2 mm sensing distance and a 0 to 0.84 mm setting distance. Its NPN output operates in NO mode through a pre-wired 2 m oil-resistant PVC cable, with a 10 to 30 VDC power supply. Ferrous metal is the specified detectable object, using an iron 4 × 4 × 1 mm standard sensing object. Response frequency is 4 kHz, current consumption is 10 mA max., and differential travel is 15% max. of sensing distance. A yellow output indicator and electrical protection functions are specified. The E2E-S05S12-WC-C1 is listed under small-diameter proximity sensors from Omron sensing products.
| Brand | Omron |
| Product | Proximity Sensors |
| Model Number | E2E-S05S12-WC-C1 2M |
Omron E2E-S05S12-WC-C1 2M Proximity Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Sensor | Small-diameter |
| Size | M5 |
| Mounting | Shielded |
| Sensing Distance | 1.2 mm |
| Setting Distance | 0 to 0.84 mm |
| Output Configuration | NPN |
| Operation Mode | NO |
| Connection | Pre Wired, Length 2M |
| Cable Specifications | PVC (oil-resistant) |
| Power Supply Voltage | 10 to 30 VDC |
| Standard Target | Iron, 4 × 4 × 1 mm |
| Differential Travel | 15% max. of sensing distance |
| Detectable Object | Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Response Frequency | 4 kHz |
| Current Consumption | 10 mA max |
| Indicator | Operation indicator: Yellow (complies with European standard EN60947-5-2) Lights during output. |
| Protection Circuit | Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, Load short-circuit protection |
| Ambient Temperature Range | Operation and storage: −25 to 70°C (with no icing or condensation) |
| Ambient Humidity Range | Operation and storage: 35% to 95% (with no condensation) |
| Insulation Resistance | ±15% max. of sensing distance at 23°C within temperature range of −25 to 70°C |
| Dielectric Strength | 50 MΩ min. (at 500 VDC) between current-carrying parts and case |
| Vibration Resistance | Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Shock Resistance | Destruction: 500 m/s2 10 times each in X, Y, and Z directions |
| Voltage Influence | ±2.5% max. of sensing distance at rated voltage in the rated voltage ±15% range |
| Degree Of Protection | IP67 |
| Weight | Approx. 35 g |
The Omron E2E-S05S12-WC-C1 2M Proximity Sensor combines an M5 shielded small-diameter body with a 1.2 mm sensing distance and a 0 to 0.84 mm setting distance. Its output is NPN with NO operation, using a pre-wired 2 m oil-resistant PVC cable on a 10 to 30 VDC supply. Ferrous metal is specified as the detectable object, while the standard sensing object is iron measuring 4 × 4 × 1 mm. Response frequency is 4 kHz, current consumption is 10 mA max., and differential travel is 15% max. of sensing distance. A yellow indicator lights during output. Protection includes output reverse polarity, power-source reverse polarity, surge suppression, and load short-circuit protection.
Operation and storage are specified from -25 to 70°C without icing or condensation and from 35% to 95% humidity. Temperature influence is ±15% max. of sensing distance at 23°C over the rated temperature range. Insulation resistance is 50 MΩ min. at 500 VDC, dielectric strength is 500 VAC for 1 minute, and voltage influence is ±2.5% max. within rated voltage ±15%. The sensor carries IP67 protection. For another small-diameter E2E model using NPN NO output and a 2 m oil-resistant cable but a 1 mm sensing distance, see E2E-C05S01-WC-C1 2M.
