Delta DVP04DA-E2 Programmable Logic Controller
The Delta DVP04DA-E2 Programmable Logic Controller (PLC) is a dependable Analog I/O Module featuring 4-channel analog output supporting -10V~+10V voltage and 0–20mA / 4–20mA current output with high-precision 14-bit resolution. Designed for stable signal generation in process automation, it operates on a secure 24VDC power supply to ensure accurate and consistent analog output performance. Manufactured by Delta, part of the Delta Programmable Logic Controller family, this module belongs to the Delta DVP-ES2/EX2 Series.
| Brand | Delta |
| Product Type | Programmable Logic Controller |
| Model Number | DVP04DA-E2 |
Delta DVP04DA-E2 Programmable Logic Controller - Technical Specifications
| Specification | Value |
|---|---|
| Power Supply Voltage | 24VDC (-15%~20%) |
| Resolution | 14-bit (-32,000 ~+32,000)/(0~+32,000) |
| Analog I/O Modules | 4 points of analog ouput |
| Fuse capacity | ES: 2A/ 250VAC; SV: 2.5A/ 30VDC |
| Power Consumption | 30VA |
| Voltage input/output | voltage ouput (-10V~+10V) |
| Current input/output | current (0~20 mA, 4~20 mA) output |
| Spike Voltage Durability | 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE) |
| Insulation Impedance | >5 MΩ (all I/O point-to-ground: 500VDC) |
| Noise Immunity | ESD: 8 kV Air Discharge EFT: Power Line, 2 kV Digital I/O: 1 kV Analog & Communication I/O: 1 kV RS: 26 MHz~1GHz, 10V/m |
| Earth | The diameter of grounding wire shall not be shorter than that of the power supply cable. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) |
| Storagr Operation Temperature | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Storage Operation Humidity | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Response Time | 3 ms/ all channels |
| Input Signal Voltage | 24VDC ±10% (5 mA) |
Delta is a globally respected brand in the field of industrial automation, known for delivering efficient, precise, and reliable control solutions. Designed to integrate seamlessly with Delta’s modular PLC systems, the DVP04DA-E2 is a proven performer in analog signal output applications. Built with industrial-grade components and backed by Delta’s engineering expertise, the Delta DVP04DA-E2 ensures stable and accurate output for diverse automation needs. This module stands as an example of how Delta PLC DVP04DA-E2 combines compact design with high-performance output control to meet the demands of modern factories and process systems.
The DVP04DA-E2 features 4 points of analog output with a 14-bit resolution (-32,000 ~ +32,000)/(0 ~ +32,000), supporting voltage output (-10V~+10V) and current output (0~20 mA, 4~20 mA). Operating on a 24VDC (-15%~20%) power supply, it offers a fast 3 ms response time across all channels. The module is built with a durable design, offering spike voltage durability of up to 1500VAC and an IP-rated protective construction. It includes strong noise immunity with ESD protection up to 8 kV, EFT resistance on power lines and I/O, and RS immunity from 26 MHz to 1 GHz at 10V/m. With a fuse capacity of ES: 2A/250VAC and SV: 2.5A/30VDC, the Delta DVP04DA-E2 is engineered for safe and long-term industrial operation.
Ideal for applications such as process control, analog signal interfacing, and precision output in manufacturing automation, the DVP04DA-E2 delivers reliable performance for industries requiring stable and accurate analog signals. It is commonly deployed in equipment where voltage or current outputs must be precisely managed, including HVAC systems, packaging machinery, and monitoring systems. Built to operate in environments with high electrical noise and varying temperatures, the DVP04DA-E2 remains a trusted choice for engineers seeking a dependable Delta Analog Output Point Extension solution.
