Delta DVP02DA-E2 Programmable Logic Controller Module
Delta DVP02DA-E2 Programmable Logic Controller module is designed for precise analog signal control in industrial automation systems where stable output regulation is required. This Delta PLC module functions as an analog output unit with dual channels, making it suitable for controlling voltage and current signals in process applications. It supports accurate signal conversion for maintaining consistent control of connected devices. The module operates on a 24VDC supply and integrates easily into modular PLC systems for flexible expansion. Developed under Delta automation solutions, it belongs to the programmable controller category and is part of the DVP-ES2 / EX2 Series PLC used in modular automation setups.
| Brand | Delta |
| Product Type | Programmable Logic Controller |
| Model Number | DVP02DA-E2 |
Delta DVP02DA-E2 Programmable Logic Controller - Technical Specifications
| Specification | Value |
|---|---|
| Power Supply Voltage | 24VDC (-15%~20%) |
| Resolution | 14-bit (-32,000 ~+32,000)/(0~+32,000) |
| Analog I/O Modules | 2 points of Analog |
| Fuse capacity | ES: 2A/ 250VAC; SV: 2.5A/ 30VDC |
| Power Consumption | 1.5W |
| Voltage input/output | voltage ouput (-10V~+10V) |
| Current input/output | current (0~20 mA, 4~20 mA) output |
| Spike Voltage Durability | 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE) |
| Insulation Impedance | >5 MΩ (all I/O point-to-ground: 500VDC) |
| Noise Immunity | ESD: 8 kV Air Discharge EFT: Power Line, 2 kV Digital I/O: 1 kV Analog & Communication I/O: 1 kV RS: 26 MHz~1GHz, 10V/m |
| Earth | The diameter of grounding wire shall not be shorter than that of the power supply cable. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) |
| Storagr Operation Temperature | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Storage Operation Humidity | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Response Time | 3 ms/ all channels |
| Input Signal Voltage | 24VDC ±10% (5 mA) |
The Delta DVP02DA-E2 is built to provide stable analog output control in systems where precise voltage and current signals are required. Its dual-channel design allows simultaneous output handling, making it suitable for applications that require consistent signal generation. The module ensures low-noise operation and stable signal conversion across different operating conditions.
In industrial applications, this module is used in process control systems, actuator drives, and automation setups where accurate analog output is essential for regulating equipment performance. It enables system integrators to control valves, drives, and other devices with precision. The compact design supports easy installation and seamless integration within existing PLC systems.
From a system integration perspective, the Delta DVP02DA-E2 fits automation environments that require compact and reliable analog output modules. It supports long-term operation under industrial conditions while maintaining consistent performance. This makes it a practical choice for applications that require precise signal control with stable and dependable output handling.
