Delta DRC-12V30W1AG 2.1A 12V 25W DIN Rail Power Supply
The Delta DRC-12V30W1AG is a compact 2.1A 12V DIN Rail Power Supply designed for industrial control panels, small automation machines, and process equipment requiring stable DC output. It operates with a nominal input voltage of 100-240Vac and supports a wide input range of 90-264Vac at 50-60Hz, ensuring efficient and reliable operation. Manufactured by Delta industrial automation products, this model belongs to Delta power supply solutions and is part of the DIN Rail Chrome Series, offering dependable performance in compact industrial setups.
| Output Current | Delta |
| Product Type | SMPS |
| Product | DRC-12V30W1AG |
Delta 2.1A 12V DIN Rail Power Supply DRC-12V30W1AG Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 2.1A |
| Output Voltage | 12V |
| Output Voltage Adjustment Range | 11.5-14.5Vdc |
| Output Power | 25W |
| Line Regulation | < 0.5% (@ 90-264Vac input, 100% load) |
| Load Regulation | < 1.0% (@ 90-264Vac input, 0-100% load) |
| PARD | < 100mVpp |
| Start-up Time | < 2,000ms @ nominal input (100% load) |
| Hold-up Time | > 25ms @ 115Vac, > 60ms @ 230Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 5% @ 90-264Vac input, 10-100% load (Slew Rate: 0.1A/μs, 50% duty cycle @ 5Hz to 100Hz) |
| Start-up with Capacitive Loads | 3,000µF Max |
| Rise Time | < 70ms @ nominal input (100% load) |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 90-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 125-375Vdc |
| Input Current | < 0.80A @ 115Vac, < 0.60A @ 230Vac |
| Efficiency at 100% load | > 85.0% @ 115Vac & 230Vac |
| Inrush Current | < 25A @ 115Vac, < 50A @ 230Vac |
| Leakage Current | < 0.25mA @ 240Vac |
| Power Dissipation | 0% load: < 0.3W @ 115Vac & 230Vac 100% load: < 4.4W @ 115Vac & 230Vac |
| Case Chassis / Cover | Plastic |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Input Terminal | 2 Pins (Rated 300V/25A) |
| Output Terminal | 4 Pins (Rated 300V/25A) |
| Noise Sound Pressure Level (SPL) | < 25dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input / Output: AWG 22-12 |
| Unit Weight | 0.14 kg (0.31 lb) |
| Vibration (Operating) | IEC 60068-2-6, Sine Wave: 10-500Hz @ 19.6m/S² (2G peak); 10 min per cycle, 60 min for all X, Y, Z directions |
| Shock Test (Operating) | IEC 60068-2-27, Half Sine Wave: 4G for a duration of 22ms, 3 shocks for each 3 directions, 9 times in total |
| Operating Temperature | -25°C to +71°C |
| Storage Temperature | -25°C to +85°C |
| Power De-rating | > 55°C de-rate power by 2.5% / °C |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Operating Altitude | 0 to 2,000 Meters (6,560 ft.) |
| Pollution Degree | 2 |
| Over Voltage Category | II |
The Delta DRC-12V30W1AG is widely used in compact control cabinets, small industrial machines, and automated equipment requiring consistent 12V DC power. Its DIN rail mounting simplifies installation and ensures organized, safe wiring. The Green LED DC OK indicator allows operators to quickly verify the power supply status, enhancing operational reliability and reducing downtime.
Built for challenging industrial environments, this 2.1A 12V DIN Rail Power Supply supports an ambient operating temperature range from -25°C to +71°C and a storage temperature range from -25°C to +85°C. Its robust design ensures continuous performance, making it suitable for automation systems, process equipment, and small-scale industrial applications that demand compact, dependable power.
For industrial setups needing reliable low-power DC solutions, the Delta DRC-12V30W1AG provides stable output, compact footprint, and operational longevity. Request a quote today to secure competitive pricing and dedicated support, ensuring peace of mind for your control panels, automation systems, and industrial machinery requiring uninterrupted 12V DC power supply.
