Delta DRC-12V60W1AG 4.5A 12V 54W DIN Rail Power Supply
The Delta DRC-12V60W1AG is a compact 4.5A 54W DIN Rail Power Supply designed for industrial control systems, automation panels, and machinery requiring stable 12V DC output. It operates on a nominal input voltage of 100-240Vac and supports a wide input range of 90-264Vac at 50-60Hz. Manufactured by Delta industrial automation products, it is part of Delta power supply solutions and belongs to the DIN Rail Chrome Series, ensuring reliable performance under demanding industrial conditions.
| Output Current | Delta |
| Product Type | SMPS |
| Product | DRC-12V60W1AG |
Delta 4.5A 54W DIN Rail Power Supply DRC-12V60W1AG Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 4.5A |
| Output Voltage | 12V |
| Output Voltage Adjustment Range | 11.5-14.0Vdc |
| Output Power | 54W |
| Line Regulation | < 0.5% (@ 90-264Vac input, 100% load) |
| Load Regulation | < 1.0% (@ 90-264Vac input, 0-100% load) |
| PARD | < 100mVpp |
| Start-up Time | < 2,000ms @ nominal input (100% load) |
| Hold-up Time | > 16ms @ 115Vac, > 60ms @ 230Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 5% @ 90-264Vac input, 10-100% load (Slew Rate: 0.1A/μs, 50% duty cycle @ 5Hz to 100Hz) |
| Start-up with Capacitive Loads | 3,000μF Max |
| Rise Time | < 70ms @ nominal input (100% load) |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 90-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 125-375Vdc |
| Input Current | < 1.50A @ 115Vac, < 1.00A @ 230Vac |
| Efficiency at 100% load | > 86.0% @ 115Vac & 230Vac |
| Inrush Current | < 30A @ 115Vac, < 60A @ 230Vac |
| Leakage Current | < 0.25mA @ 240Vac |
| Power Dissipation | 0% load: < 0.35W @ 115Vac & 230Vac 100% load: < 8.75W @ 115Vac & 230Vac |
| Case Chassis / Cover | Plastic |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Input Terminal | 2 Pins (Rated 300V/25A) |
| Output Terminal | 4 Pins (Rated 300V/25A) |
| Noise Sound Pressure Level (SPL) | < 25dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input/Output: AWG 20-12 |
| Unit Weight | 0.22 kg (0.49 lb) |
| Vibration (Operating) | IEC 60068-2-6, Sine Wave: 10-500Hz @ 19.6m/S² (2G peak); 10 min per cycle, 60 min for all X, Y, Z directions |
| Shock Test (Operating) | IEC 60068-2-27, Half Sine Wave: 4G for a duration of 22ms, 3 shocks for each 3 directions, 9 times in total |
| Operating Temperature | -25°C to +71°C |
| Storage Temperature | -25°C to +85°C |
| Power De-rating | > 55°C de-rate power by 2.5% / °C |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Operating Altitude | 0 to 2,000 Meters (6,560 ft) |
| Pollution Degree | 2 |
| Over Voltage Category | II |
The Delta DRC-12V60W1AG is widely used in industrial control cabinets, compact automated machines, and small process systems where consistent 12V DC power is critical. Its DIN rail mounting facilitates easy installation and organized wiring, while the Green LED DC OK indicator provides immediate feedback on operational status, minimizing downtime and maintaining continuous power supply.
Engineered for harsh industrial environments, this 4.5A 54W DIN Rail Power Supply operates efficiently across an ambient temperature range from -25°C to +71°C and supports storage temperatures from -25°C to +85°C. Its rugged design ensures stable DC output under varying operating conditions, making it ideal for machinery, control panels, and small automation systems that require compact, dependable power solutions.
For industries seeking reliable and durable power supplies, the Delta DRC-12V60W1AG guarantees consistent output, long-term operational stability, and a space-saving design. Request a quote today to access competitive pricing and responsive support, ensuring your industrial systems, control panels, and automation equipment operate seamlessly with uninterrupted 12V DC power.
