Baumer EN580C.ML-BN12.GH3C1.21160.A Rotary Encoder
Technical Specifications of Baumer 16 bit Absolute Encoder EN580C.ML-BN12.GH3C1.21160.A 11266959:
| Voltage supply | 8...30 VDC |
| Interface | CANopen® |
| Sensing method | Optical |
| Connection | Connector 2xM12 |
Baumer EN580C.ML-BN12.GH3C1.21160.A Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 8...30 VDC |
| Reverse polarity protection | Yes |
| Consumption w/o load | ≤100 mA (24 VDC) |
| Interface | CANopen® |
| Function | Multiturn |
| Absolute accuracy | ±0.01 ° |
| Sensing method | Optical |
| Status indicator | DUO-LED integrated in bus cover |
| Size (flange) | ø58 mm |
| Shaft type | ø12 mm (blind hollow shaft) |
| Protection EN 60529 | IP 54 (without shaft seal) |
| Operating speed | ≤6000 rpm (+25 °C) |
| Starting acceleration | ≤1000 U/s² |
| Starting torque | ≤0.02 Nm (+25 °C, IP 54) |
| Material | Housing: aluminium, Flange: aluminium, Bus cover: zinc die-cast, Shaft: stainless steel |
| Operating temperature | -40...+85 °C (see general information) |
| Relative humidity | 95 % non-condensing |
| Resistance | EN 60068-2-6, Vibration ±0.75 mm - 10-58 Hz, 10 g - 58-2000 Hz, EN 60068-2-27, Shock 200 g, 3 ms |
| Weight approx. | 550 g |
| Connection | Connector 2xM12 |
| Profile conformity | CANopen® CiA 301 V4.2.0 |
Send Your Inquiry for Baumer 16 bit Absolute Encoder EN580C.ML-BN12.GH3C1.21160.A part no: 11266959 with cost-effective solutions. Essential Technical Specs of EN580C.ML-BN12.GH3C1.21160.A, 11266959 are voltage supply of 8...30 VDC. These encoders feature the CANopen® interface, Multiturn functionality, and Optical sensing methods for accurate performance. The flange size is ø58 mm, making them suitable for various industrial applications. The operating speed reaches up to ≤6000 rpm (+25 °C) operations, ensuring reliable functionality in demanding environments. The Housing: aluminium, Flange: aluminium, Bus cover: zinc die-cast, Shaft: stainless steel, provides robust protection. The connection is facilitated by Connector 2xM12, ensuring secure and efficient data transmission. Capture the Best Deal with a Quote for your requirement of Baumer 16 bit Absolute Encoder. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
