optoTurn EN580E.ML-TT14.GE1B1.13120.H: 11246070 - Baumer IP 65 Housing Side

Technical Specifications of Baumer Encoder IP 65 Housing Side optoTurn EN580E.ML-TT14.GE1B1.13120.H 11246070:

SpecValue
Voltage supply8...30 VDC
InterfaceBiSS C Certified
Sensing methodOptical
ConnectionFlylead connector M23, 12-pin, tangential, length 300 mm

Baumer Encoder IP 65 Housing Side optoTurn EN580E.ML-TT14.GE1B1.13120.H 11246070 Technical Specifications:

SpecificationValue
Voltage supply8...30 VDC
Reverse polarity protectionYes
Consumption w/o load≤80 mA (24 VDC)
InterfaceBiSS C Certified
FunctionMultiturn
Total resolution
Absolute accuracy±0.03 °
Sensing methodOptical
Status indicator
Size (flange)ø58 mm
Shaft typeø14 mm (through hollow shaft)
Protection EN 60529IP 54 (flange side), IP 65 (housing side)
Operating speed≤6000 rpm (+25 °C)
Starting acceleration
Starting torque≤0.04 Nm
Rotor moment of inertia
MaterialHousing: aluminium, Shaft: stainless steel
Operating temperature-25...+85 °C (see general information)
Relative humidity95 % non-condensing
ResistanceIEC 60068-2-6, Vibration ±0.75 mm - 10-58 Hz, 10 g - 58-2000 Hz, EN 60068-2-27, Shock 100 g, 11 ms
Weight approx.400 g
ConnectionFlylead connector M23, 12-pin, tangential, length 300 mm
Flange
Admitted shaft load
Consumption typ.
Initializing time
Data currency
Profile conformity
Code sequenceCW: ascending values with clockwise sense of rotation (looking at flange)
Output stagesBiSS data: Linedriver RS422
Incremental output
Output signalsBiSS data (SLO)
Output frequency
Moment of inertia
Working distance
Give Us a Call for Baumer Encoder IP 65 Housing Side optoTurn EN580E.ML-TT14.GE1B1.13120.H part no: 11246070 with budget-friendly prices. Technical Attributes are optoTurn EN580E.ML-TT14.GE1B1.13120.H, 11246070 include voltage supply of 8...30 VDC. These encoders feature the BiSS C Certified interface, Multiturn functionality, and Optical sensing methods for accurate performance. The flange size is ø58 mm, making them suitable for various industrial applications. The operating speed reaches up to ≤6000 rpm (+25 °C) operations, ensuring reliable functionality in demanding environments. The Housing: aluminium, Shaft: stainless steel, provides robust protection. The connection is facilitated by Flylead connector M23, 12-pin, tangential, length 300 mm, ensuring secure and efficient data transmission. Navigate Your Needs with a Quote for your requirement of Baumer Encoder IP 65 Housing Side. We excel in offering more cost-effective and supportive solutions than other Competitors.
