PRO TOP2 120W 24V 5A UW EX: 2467240000 - Weidmuller SMPS 24 Volt 5 Ampere
Weidmuller SMPS 24 Volt 5 Ampere PRO TOP2 120W 24V 5A UW EX, 2467240000 Technical Specifications:
| Brand | Weidmuller |
| Product Type | SMPS(Switch Mode Power Supply) |
| Product | PRO TOP2 120W 24V 5A UW EX |
Weidmuller SMPS 24 Volt 5 Ampere PRO TOP2 120W 24V 5A UW EX, 2467240000 Technical Specifications:
| Specification | Value |
|---|---|
| Depth | 125 mm |
| Height | 130 mm |
| Width | 39 mm |
| AC input voltage range | 85...550 V AC |
| Connection system | Clamping yoke |
| DC input voltage range | 90...800 V DC |
| Frequency range AC | 45…65 Hz |
| Rated input voltage | 100 - 500 V AC / 120 - 500 V DC |
| Surge protection | Varistor |
| Rated output current | 5 A @ 60 °C |
| Output power | 120 W |
| Output voltage, max. | 28.8 V |
| Output voltage, min. | 22.5 V |
| Rated output voltage | 24 V DC ± 1 % |
| Protection degree | IP20 |
| Wire connection method | Screw connection |
| Storage temperature | -40 °C...85 °C |
| Operating temperature | -40 °C...75 °C |
| Weight | 892 g |
IndMALL offers Weidmuller SMPS 24 Volt 5 Ampere PRO TOP2 120W 24V 5A UW EX Order no: 2467240000 at attractive prices. Engineering Specifications of PRO TOP2 120W 24V 5A UW EX, 2467240000 are 125 mm depth, 130 mm height, 39 mm width, 85...550 V AC & 90...800 V DC input voltage, 45…65 Hz frequency, Clamping yoke connection, 100 - 500 V AC / 120 - 500 V DC rated input voltage, 24 V DC ± 1 % rated output voltage, 5 A @ 60 °C current, 120 W output power, Screw connection wire connection, Varistor surge protection & IP20 degree of protection. Match Your Needs with a Quote for your requirement of Weidmuller SMPS 24 Volt 5 Ampere. Our pricing and support are unrivaled, especially when compared to other Dealers.
