PRO TOP1 480W 48V 10A EX: 2467040000 - Weidmuller 48 Volt SMPS
Weidmuller 48 Volt SMPS PRO TOP1 480W 48V 10A EX, 2467040000 Technical Specifications:
| Brand | Weidmuller |
| Product Type | SMPS(Switch Mode Power Supply) |
| Product | PRO TOP1 480W 48V 10A EX |
Weidmuller 48 Volt SMPS PRO TOP1 480W 48V 10A EX, 2467040000 Technical Specifications:
| Specification | Value |
|---|---|
| Depth | 125 mm |
| Height | 130 mm |
| Width | 68 mm |
| AC input voltage range | 85…277 V AC |
| Connection system | Clamping yoke |
| DC input voltage range | 80 ... 410 V DC |
| Frequency range AC | 45…65 Hz |
| Rated input voltage | 110...240 V AC / 120...340 V DC |
| Surge protection | Varistor |
| Rated output current | 10 A @ 60 °C |
| Output power | 480 W |
| Output voltage, max. | 56 V |
| Output voltage, min. | 45 V |
| Rated output voltage | 48 V DC ± 1 % |
| Protection degree | IP20 |
| Wire connection method | Screw connection |
| Storage temperature | -40 °C...85 °C |
| Operating temperature | -40 °C...70 °C |
| Weight | 1,520 g |
Send Us an Email for Weidmuller 48 Volt SMPS PRO TOP1 480W 48V 10A EX Order no: 2467040000 with budget-friendly prices. Technical Attributes of PRO TOP1 480W 48V 10A EX, 2467040000 includes 125 mm depth, 130 mm height, 68 mm width, 85…277 V AC & 80 ... 410 V DC input voltage, 45…65 Hz frequency, Clamping yoke connection, 110...240 V AC / 120...340 V DC rated input voltage, 48 V DC ± 1 % rated output voltage, 10 A @ 60 °C current, 480 W output power, Screw connection wire connection, Varistor surge protection & IP20 degree of protection. Now's the Time to Secure a Quote for your requirement of Weidmuller 48 Volt SMPS. Rest assured, our pricing and support outshine other Suppliers.
