PRO PM 75W 5V 14A: 2660200281 - Weidmuller 75W 14A SMPS
Weidmuller 75W 14A SMPS PRO PM 75W 5V 14A, 2660200281 Technical Specifications:
| Brand | Weidmuller |
| Product Type | SMPS(Switch Mode Power Supply) |
| Product | PRO PM 75W 5V 14A |
Weidmuller 75W 14A SMPS PRO PM 75W 5V 14A, 2660200281 Technical Specifications:
| Specification | Value |
|---|---|
| Depth | 99 mm |
| Height | 30 mm |
| Width | 97 mm |
| AC input voltage range | 90…264 V AC |
| Connection system | Screw connection |
| DC input voltage range | - |
| Frequency range AC | 47...63 Hz |
| Rated input voltage | 100...240 V AC |
| Surge protection | 5.6...6.8 V @ 5 V DC |
| Rated output current | 14 A |
| Output power | 75 W |
| Output voltage, max. | - |
| Output voltage, min. | - |
| Rated output voltage | 5 V DC |
| Protection degree | IP20 |
| Wire connection method | Screw connection |
| Storage temperature | -40 °C...85 °C |
| Operating temperature | -20 °C...70 °C |
| Weight | 240 g |
Ask for the Pricing of Weidmuller 75W 14A SMPS PRO PM 75W 5V 14A Order no: 2660200281 at unbeatable prices. Detailed Specifications of PRO PM 75W 5V 14A, 2660200281 feature 99 mm depth, 30 mm height, 97 mm width, 90…264 V AC input voltage, 47...63 Hz frequency, Screw connection, 100...240 V AC rated input voltage, 5 V DC rated output voltage, 14 A current, 75 W output power, 5.6...6.8 V @ 5 V DC surge protection & IP20 degree of protection. Now's the Time to Secure a Quote for your requirement of Weidmuller 75W 14A SMPS. We're committed to offering more favorable pricing and more responsive support than other Traders.
