PRO BAS 240W 24V 10A: 2838460000 - Weidmuller 24V 10A SMPS
Weidmuller 24V 10A SMPS PRO BAS 240W 24V 10A, 2838460000 Technical Specifications:
| Brand | Weidmuller |
| Product Type | SMPS(Switch Mode Power Supply) |
| Product | PRO BAS 240W 24V 10A |
Weidmuller 24V 10A SMPS PRO BAS 240W 24V 10A, 2838460000 Technical Specifications:
| Specification | Value |
|---|---|
| Depth | 100 mm |
| Height | 130 mm |
| Width | 52 mm |
| AC input voltage range | 85...264 V AC (derating at 100 V AC) |
| Connection system | Screw connection |
| DC input voltage range | 110...370 V DC (derating at <120 V DC) |
| Frequency range AC | 45β¦65 Hz |
| Rated input voltage | 110...240 V AC / 120...340 V DC |
| Surge protection | - |
| Rated output current | 10 A @ 55 Β°C 6.25 A @ 70Β°C |
| Output power | 240 W |
| Output voltage, max. | 28 V |
| Output voltage, min. | 22 V |
| Rated output voltage | 24 V DC |
| Protection degree | IP20 |
| Wire connection method | Screw connection |
| Storage temperature | -40 Β°C...85 Β°C |
| Operating temperature | -25 Β°C...70 Β°C |
| Weight | 693 g |
Mail Us for Weidmuller 24V 10A SMPS PRO BAS 240W 24V 10A Order no: 2838460000 at unbeatable prices. Detailed Specifications of PRO BAS 240W 24V 10A, 2838460000 feature 100 mm depth, 130 mm height, 52 mm width, 85...264 V AC (derating at 100 V AC) & 110...370 V DC (derating at <120 V DC) input voltage, 45β¦65 Hz frequency, Screw connection, 110...240 V AC / 120...340 V DC rated input voltage, 24 V DC rated output voltage, 10 A current, 240 W output power, IP20 degree of protection. Elevate Your Project with a Quote for your requirement of Weidmuller 24V 10A SMPS. Count on us for more economical pricing and more reliable support than other Traders & Suppliers.
