Schneider HMISTO705 Human Machine interface
The Schneider Electric HMISTO705 is a Magelis HMI with a 4.3" TFT LCD display, offering 65536 colors and a PROFINET interface. Designed for industrial automation, this HMI panel provides touch operation and is configured with WinCC Basic for efficient integration into automation systems.
| Brand | Schneider |
| Product Type | Human Machine Interface (HMI) |
| Product | HMISTO705 |
Schneider HMISTO705 Human Machine interface – Technical Specifications
| Specification | Value |
|---|---|
| Display Resolution | 480 x 272 pixels |
| Realtime clock | With RTC-battery set optional |
| NEMA degree of protection | NEMA 4X/13 front panel indoor use) |
| Depth | - |
| Display size | 4.3 inch |
| Resistance to electromagnetic fields | - |
| Display colour | 65536 colours |
| Width | - |
| Cut-out dimensions | 77.5 x 112.5 mm66 x 105 mm with mounting adaptor |
| Enclosure Material | PPT |
| Processor frequency | - |
| Power Consumption in W | 7.5 W |
| [Us] rated supply voltage | 12...24 V DC - 10...20 % |
| Electromagnetic compatibility | Resistance to radiated electromagnetic fields - test level: 10 V/m (80 MHz...2.7 GHz)Resistance to electrostatic discharge - test level: 8 kV level 3 (air discharge) conforming to EN 61000-4-2Resistance to electrostatic discharge - test level: 6 kV level 3 (direct contact) conforming to EN 61000-4-2 |
| Relative humidity | 10…90 % without condensation |
| Height | - |
| IP degree of protection | IP65f front panel)IP20 rear panel) |
| Net Weight | 0.49 lb(US) (0.22 kg) |
| Range of Product | Harmony STO & STU |
| Ambient Air Temperature for Operation | 32…122 °F (0…50 °C) |
| Inrush current | - |
| Integrated connection type | 1 USB 2.0 type mini B1 USB 2.0 type A1 serial link - 9-pin terminal block - RS232C 2400...115200 bps) |
| Display Type | Colour TFT LCD |
| Operating System | Harmony |
| Touch panel | Analogue |
| Memory description | Back up of data 512 KBApplication memory 26 MB |
| Ambient Air Temperature for Storage | -4…140 °F (-20…60 °C) |
| Vibration resistance | 1 gn 5…150 Hz) IEC 61131-23.5 mm constant amplitude 5…150 Hz) IEC 61131-2 |
| Brightness | 16 levels via touch panel |
| Product or Component Type | Touch panel screen |
| Operating altitude | 6561.68 ft (2000 m) |
| Shock resistance | 15 gn 11 msIEC 61131-2 |
| Supply | External source |
The Schneider Electric HMISTO705 is a compact and efficient HMI (Human Machine Interface) from the Magelis Harmony STO & STU range, designed for reliable visualization and control in industrial automation systems. Featuring a 4.3-inch TFT LCD display with 480 x 272 pixel resolution and 65,536 colors, it provides sharp, vibrant visuals for operators managing production lines, machines, and process control tasks.
Built for industrial reliability, the HMISTO705 operates on a 12–24 V DC power supply with just 7.5 W consumption, ensuring energy-efficient performance in continuous use. Its IP65-rated front panel and NEMA 4X/13 protection safeguard against dust, water, and harsh factory conditions, while the IP20 rear panel ensures safe integration in control enclosures. Equipped with 26 MB application memory and 512 KB backup memory, this HMI provides reliable data handling. Connectivity is versatile with USB 2.0 Type A, USB mini-B, and RS232C serial link, enabling seamless integration with controllers and devices. It supports the Harmony operating system, includes an optional real-time clock, and ensures stable performance with vibration resistance (IEC 61131-2) and shock resistance up to 15 gn.
In practical use, the Schneider HMISTO705 Magelis HMI is widely deployed in compact control panels, packaging lines, and machine interfaces where space-saving, energy efficiency, and reliability are crucial. Its lightweight build of just 0.22 kg, combined with cut-out dimensions of 77.5 x 112.5 mm, makes it easy to install in small enclosures without sacrificing performance. With brightness adjustment (16 levels via touch), multilingual font support, and compliance with international EMC and safety standards, it provides operators with a robust and user-friendly interface. Trusted for its precision, compact size, and integration flexibility, the HMISTO705 is a cost-effective choice for modern industrial automation.
