Schmersal BN 85-R Magnetic Reed Switch
The Schmersal BN 85-R Magnetic Reed Switch (Item No: 101091836) offers a Magnetic drive working principle, 1,000,000,000 Operationsmechanical life, minimum, IP40 degree of protection, bistable contact switching element. Manufactured by Schmersal under the Schmersal Magnetic Reed Switch. category, this model belongs to the Schmersal BN Series.
| Brand | Schmersal |
| Product Type | Magnetic Reed Switch |
| Model Number | BN 85-R |
Schmersal BN 85-R Magnetic Reed Switch β Technical Specifications
| Specification | Value |
|---|---|
| Working principle | Magnetic drive |
| Housing construction form | Block |
| Housing material | Glass-fibre, reinforced thermoplastic |
| Gross weight | 40 g |
| Latching | Yes |
| Suitable for elevators | Yes |
| Number of snap-in contacts | 1 |
| Actuating panels | front side |
| Actuating element | Magnet |
| Mechanical life, minimum | 1,000,000,000 Operations |
| Actuating speed, maximum | 18 m/s |
| Mounting | clamping foot and 2 single wires |
| Length of cable | 1 m |
| Termination | Cable |
| Wire cross-section | 18 AWG |
| Material of the Cable mantle | LiY |
| Length of sensor | 16.5 mm |
| Width of sensor | 40 mm |
| Height of sensor | 35 mm |
| Degree of protection | IP40 |
| Ambient temperature | -25 ... +80 Β°C |
| Restistance to shock | 60 g, on sine wave oscillation |
| Switching voltage, maximum | 60 VDC |
| Switching current, maximum | 1 A |
| Switching capacity, maximum | 30 W |
| Switching element | bistable contact |
| Bounce duration, maximum | 0.2 ms |
| Design of control elements | Reed contacts |
| Scope of delivery | Actuator must be ordered separately. |
| Recommendation (actuator) | BP 10 S2x BP 10 SBP 15 SBP 34 SBP 20 SBP 31 SBP 11 SBP 12 SBP 6 SBP 8 S2 x BP 15 S |
| Recommendation (actuator, lift switchgear) | BP 10BP 62 x BP 152 x BP 10BP 15BP 34 |
IndMALL Automation Dealing offers Schmersal Magnetic reed switch BN 85-R Item No: 101091836 at unbeatable prices. The Main Technical Parameters of BN 85-R, 101091836 feature Magnetic drive working principle, this sensor features a durable Block style housing made from Glass-fibre, reinforced thermoplastic, ensuring strength and longevity. It uses an Magnet as the actuating element and offers Cable termination for straightforward integration. With a compact sensor length of 16.5 mm, this unit is ideal for space-constrained setups. The switch supports a maximum switching voltage of 60 VDC and a switching capacity of up to 30 W, making it suitable for low-power control tasks. It utilizes a bistable contact system with integrated Reed contacts, providing reliable switching performance. The control element design is optimized for simple and safe operation. Rated at IP40, itβs suited for protected environments and operates in a wide ambient temperature range from -25 ... +80 Β°C. Take the First Step with a Quote for your requirement of Magnetic reed switch BN 85-R. Choose us for unparalleled pricing and support over other Dealers & Distributors.
