Puls CD5.242 Power Supply
The Puls CD5.242 Power Supply offers 24 Vdc, DIN rail Mounting Method, Screw terminals Connection Method, 4.3 A at 28 V output current. Manufactured by Puls under the Puls Power Supply category, this model belongs to the 3-phase system
| Brand | Puls |
| Product Type | Power Supply |
| Model Number | CD5.242 |
Puls CD5.242 Power Supply – Technical Specifications
| Specification | Value |
|---|---|
| DC Input voltage | DC 48 V (± 25 %) |
| Harmonic correction | - |
| Power factor | - |
| Input inrush current limitation | - |
| Input inrush current | - |
| External input fuse recommendation | - |
| Nominal voltage | 24 Vdc |
| Adjustment range | 24 - 28 V |
| Output current range | 5 - 4.3 A |
| Output current | 4.3 A at 28 V |
| Output power | 120 W |
| Derating | 3 W/°C for >+60 °C |
| Ripple and noise voltage max. | 50 mVpp |
| Dimensions (WxHxD) | 32 mm x 124 mm x 102 mm |
| Weight per unit (excl. packaging) | 425 g |
| Mounting method | DIN rail |
| Operating temp. range | -25 °C to 70 °C |
| Connection method | Screw terminals |
| Efficiency, typ. | 90.3 % |
| Power losses, typ. | 12.9 W |
