Phoenix PLC-RSC-230UC/ 2AU/SEN Relay Module
The Phoenix PLC-RSC-230UC/ 2AU/SEN Relay Module (Part No: 2966443 ) offers a 230 V AC nominal input voltage UN, 179.4 V AC/DC ... 264.5 V AC/DC (20 °C) input voltage range, polarized Drive, AgSnO, hard gold-plated contact material. Manufactured by Phoenix under the Phoenix Relay Module category, this model belongs to the Phoenix PLC Series.
| Brand | Phoenix Contact |
| Product Type | Relay Module |
| Model Number | PLC-RSC-230UC/ 2AU/SEN |
Phoenix PLC-RSC-230UC/ 2AU/SEN Relay Module – Technical Specifications
| Specification | Value |
|---|---|
| Product type | Relay Module |
| Product family | PLC-INTERFACE |
| Application | Input function |
| Mechanical service life | - |
| Insulation | - |
| Overvoltage category | III |
| Pollution degree | - |
| Maximum power dissipation for nominal condition | 0.74 W |
| Test voltage (Winding/contact) | - |
| Test voltage (Changeover contact/changeover contact) | - |
| Rated surge voltage | - |
| Nominal input voltage UN | 230 V AC |
| Input voltage range | 179.4 V AC/DC ... 264.5 V AC/DC (20 °C) |
| Drive and function | monostable |
| Drive (polarity) | polarized |
| Typical input current at UN | 3.2 mA |
| Typical response time | - |
| Typical release time | - |
| Protective circuit | Bridge rectifier |
| Operating voltage display | yes |
| Contact switching type | 1 N/C contact |
| Type of switch contact | Single contact |
| Contact material | AgSnO, hard gold-plated |
| Maximum switching voltage | 250 V AC/DC |
| Limiting continuous current | 6 A |
| Maximum inrush current | 50 mA |
| Min. switching current | 1 mA |
| Interrupting rating (ohmic load) max. | 140 W (at 24 V DC) |
| Switching capacity | 2 A (at 24 V, DC13) |
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Conductor cross section rigid | 0.14 mm² ... 2.5 mm² |
| Conductor cross section flexible | 0.14 mm² ... 2.5 mm² |
| Conductor cross section AWG | 26 ... 14 |
| Tightening torque | 0.6 Nm ... 0.8 Nm |
| Width | 6.2 mm |
| Height | 80 mm |
| depth | 94 mm |
| Color | - |
| Flammability rating according to UL 94 | V0 (Housing) |
| Degree of protection (Relay) | - |
| Degree of protection (Relay base) | IP20 (Relay base) |
| Ambient temperature (operation) | -25 °C ... 55 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Temperature | D |
| Humidity | A |
| Vibration | B/C |
| EMC | B |
| Enclosure | Required protection according to the Rules shall be provided upon installation on board |
| Low Voltage Directive | Conformance with Low Voltage Directive |
| Electromagnetic compatibility | Conformance with EMC directive |
| Standards/regulations | - |
| Mounting Type | DIN rail mounting |
| Mounting position | - |
| Contact Connection type | - |
| Output fuse | 4 A gL/gG NEOZED |
| Degree of protection (Installation location) | - |
Give Us a Call for Phoenix PLC Relay 230V Input PLC-RSC-230UC/ 2AU/SEN part no: 2966443 with budget-friendly prices. Technical Attributes are PLC-RSC-230UC/ 2AU/SEN, 2966443 include Relay Module type and PLC-INTERFACE Product family a versatile solution for Input function applications. This relay module features a mechanical service life of -, ensuring durability and reliability. With a maximum power dissipation of 0.74 W, it operates efficiently at a nominal input voltage of 230 V AC, within an input voltage range of 179.4 V AC/DC ... 264.5 V AC/DC (20 °C). The module has a typical input current of 3.2 mA at UN, with a response time of - and a release time of -. It is equipped with a Bridge rectifier for protection and includes 1 N/C contact made from Screw connection Connection method. Navigate Your Needs with a Quote for your requirement of Phoenix PLC Relay 230V Input. We excel in offering more cost-effective and supportive solutions than other Competitors.
