PLC-RSC-120UC/ 1AU/MS/SEN: 2909664 - Phoenix PLC-BSC SEN 120V Relay
Technical Specifications of Phoenix PLC-BSC SEN 120V Relay PLC-RSC-120UC/ 1AU/MS/SEN 2909664:
Spec | Value |
---|---|
Product type | Relay Module |
Nominal input voltage UN | 120 V AC |
Connection method | Screw connection |
Mounting type | DIN rail mounting |
Phoenix PLC-INTERFACE with Switch PLC-RPT- 24UC/ 1/S/H, 2900328 Technical Specifications:
Specification | Value |
---|---|
Product type | Relay Module |
Product family | PLC-INTERFACE |
Application | Palm switch |
Mechanical service life | 1x 107 cycles |
Insulation | - |
Overvoltage category | III |
Pollution degree | - |
Maximum power dissipation for nominal condition | 0.42 W |
Test voltage (Winding/contact) | 4 kV AC (50 Hz, 1 min., winding/contact) |
Test voltage (Changeover contact/changeover contact) | - |
Rated surge voltage | - |
Nominal input voltage UN | 120 V AC |
Input voltage range | 93.6 V AC/DC ... 168 V AC/DC (20 °C) |
Drive and function | monostable |
Drive (polarity) | polarized |
Typical input current at UN | 3.5 mA |
Typical response time | 6 ms |
Typical release time | 15 ms |
Protective circuit | Bridge rectifier; Bridge rectifier |
Operating voltage display | Yellow LED |
Contact switching type | 1 N/O contact |
Type of switch contact | Single contact |
Contact material | AgSnO, hard gold-plated |
Maximum switching voltage | 250 V AC/DC |
Limiting continuous current | 6 A |
Maximum inrush current | 50 mA |
Min. switching current | 10 mA (at 12 V) |
Interrupting rating (ohmic load) max. | 140 W (at 24 V DC) |
Switching capacity | 2 A (at 24 V, DC13) |
Connection method | Screw connection |
Stripping length | 8 mm |
Conductor cross section rigid | 0.14 mm² ... 2.5 mm² |
Conductor cross section flexible | 0.14 mm² ... 2.5 mm² |
Conductor cross section AWG | 26 ... 14 |
Tightening torque | 0.6 Nm ... 0.8 Nm |
Width | 6.2 mm |
Height | 80 mm |
depth | 94 mm |
Color | gray (RAL 7042) |
Flammability rating according to UL 94 | V0 (Housing) |
Degree of protection (Relay) | RT II (Relay) |
Degree of protection (Relay base) | IP20 (Relay base) |
Ambient temperature (operation) | -40 °C ... 60 °C |
Ambient temperature (storage/transport) | -40 °C ... 85 °C |
Temperature | D |
Humidity | A |
Vibration | B/C |
EMC | B |
Enclosure | Required protection according to the Rules shall be provided upon installation on board |
Low Voltage Directive | Conformance with Low Voltage Directive |
Electromagnetic compatibility | Conformance with EMC directive |
Standards/regulations | IEC 60664 |
Mounting Type | DIN rail mounting |
Mounting position | any |
Contact Connection type | - |
Output fuse | 4 A gL/gG NEOZED |
Degree of protection (Installation location) | - |
Please speak to our Technical Engineer for Phoenix PLC-BSC SEN 120V Relay PLC-RSC-120UC/ 1AU/MS/SEN part no: 2909664 at attractive prices. Technical Specs Summary of PLC-RSC-120UC/ 1AU/MS/SEN, 2909664 includes Relay Module type and PLC-INTERFACE Product family a versatile solution for Palm switch applications. This relay module features a mechanical service life of 1x 107 cycles, ensuring durability and reliability. With a maximum power dissipation of 0.42 W, it operates efficiently at a nominal input voltage of 120 V AC, within an input voltage range of 93.6 V AC/DC ... 168 V AC/DC (20 °C). The module has a typical input current of 3.5 mA at UN, with a response time of 6 ms and a release time of 15 ms. It is equipped with a Bridge rectifier; Bridge rectifier for protection and includes 1 N/O contact made from Screw connection Connection method. Match Your Needs with a Quote for your requirement of Phoenix PLC-BSC SEN 120V Relay. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
