PLC-RSC-125DC/21/MS: 2909652 - Phoenix 125 V DC Input Voltage Relay

Technical Specifications of Phoenix 125 V DC Input Voltage Relay PLC-RSC-125DC/21/MS 2909652:

SpecValue
Product typeRelay Module
Nominal input voltage UN125 V DC
Connection methodScrew connection
Mounting typeDIN rail mounting

Phoenix 120VAC/DC Input Voltage Relay EMG 10-REL/KSR-120/ 1-LC, 2964432 Technical Specifications:

SpecificationValue
Product typeRelay Module
Product familyPLC-INTERFACE
ApplicationPalm switch
Mechanical service life1x 107 cycles
Insulation-
Overvoltage categoryIII
Pollution degree-
Maximum power dissipation for nominal condition0.22 W
Test voltage (Winding/contact)4 kV AC (50 Hz, 1 min., winding/contact)
Test voltage (Changeover contact/changeover contact)-
Rated surge voltage-
Nominal input voltage UN125 V DC
Input voltage range96.3 V DC ... 175 V DC (20 °C)
Drive and functionmonostable
Drive (polarity)polarized
Typical input current at UN3 mA
Typical response time5 ms
Typical release time8 ms
Protective circuitReverse polarity protection; Polarity protection diode
Operating voltage displayYellow LED
Contact switching type1 changeover contact
Type of switch contactSingle contact
Contact materialAgSnO
Maximum switching voltage250 V AC/DC (The separating plate PLC-ATP should be installed for voltages larger than 250 V (L1, L2, L3) between identical terminal blocks in adjacent modules. Potential bridging is then carried out with FBST 8-PLC... or ...FBST 500...)
Limiting continuous current6 A
Maximum inrush current10 A (4 s)
Min. switching current10 mA (12 V)
Interrupting rating (ohmic load) max.140 W (at 24 V DC)
Switching capacity2 A (at 24 V, DC13)
Connection methodScrew connection
Stripping length8 mm
Conductor cross section rigid0.14 mm² ... 2.5 mm²
Conductor cross section flexible0.14 mm² ... 2.5 mm²
Conductor cross section AWG26 ... 14
Tightening torque0.6 Nm ... 0.8 Nm
Width6.2 mm
Height80 mm
depth94 mm
Colorgray (RAL 7042)
Flammability rating according to UL 94V0 (Housing)
Degree of protection (Relay)RT II (Relay)
Degree of protection (Relay base)IP20 (Relay base)
Ambient temperature (operation)-40 °C ... 55 °C
Ambient temperature (storage/transport)-40 °C ... 85 °C
TemperatureD
HumidityA
VibrationB/C
EMCB
EnclosureRequired protection according to the Rules shall be provided upon installation on board
Low Voltage DirectiveConformance with Low Voltage Directive
Electromagnetic compatibilityConformance with EMC directive
Standards/regulationsIEC 60664
Mounting TypeDIN rail mounting
Mounting positionany
Contact Connection typePower contact
Output fuse4 A gL/gG NEOZED
Degree of protection (Installation location)-
Get A Quote for Phoenix 125 V DC Input Voltage Relay PLC-RSC-125DC/21/MS part no: 2909652 at the best price. Here are the brief Technical Specifications of PLC-RSC-125DC/21/MS, 2909652 are Relay Module type and PLC-INTERFACE Product family a versatile solution for Palm switch applications. This relay module features a mechanical service life of 1x 107 cycles, ensuring durability and reliability. With a maximum power dissipation of 0.22 W, it operates efficiently at a nominal input voltage of 125 V DC, within an input voltage range of 96.3 V DC ... 175 V DC (20 °C). The module has a typical input current of 3 mA at UN, with a response time of 5 ms and a release time of 8 ms. It is equipped with a Reverse polarity protection; Polarity protection diode for protection and includes 1 changeover contact made from Screw connection Connection method. It's Time to get a Quote for your requirement of Phoenix 125 V DC Input Voltage Relay. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
