DEK-REL- 24/1/S: 2964131 - Phoenix Contact Terminal Width 6.2 mm Relay
Technical Specifications of Phoenix Contact Terminal Width 6.2 mm Relay DEK-REL- 24/1/S 2964131:
Spec | Value |
---|---|
Product type | Relay Module |
Nominal input voltage UN | 24 V AC/DC |
Connection method | Screw connection |
Mounting type | DIN rail mounting |
Phoenix 125 V DC Input Voltage Relay PLC-RSC-125DC/21/MS, 2909652 Technical Specifications:
Specification | Value |
---|---|
Product type | Relay Module |
Product family | DEK |
Application | Palm switch |
Mechanical service life | approx. 2x 107 cycles |
Insulation | Basic insulation |
Overvoltage category | III |
Pollution degree | 2 |
Maximum power dissipation for nominal condition | 0.16 W |
Test voltage (Winding/contact) | 2 kV AC (50 Hz, 1 min., winding/contact) |
Test voltage (Changeover contact/changeover contact) | - |
Rated surge voltage | - |
Nominal input voltage UN | 24 V AC/DC |
Input voltage range | 19.2 V AC/DC ... 26.4 V AC/DC (20 °C) |
Drive and function | monostable |
Drive (polarity) | polarized |
Typical input current at UN | 6.5 mA |
Typical response time | 5 ms |
Typical release time | 15 ms |
Protective circuit | Bridge rectifier; Bridge rectifier |
Operating voltage display | Yellow LED |
Contact switching type | 1 N/O contact |
Type of switch contact | Double contact |
Contact material | AgNi, hard gold-plated |
Maximum switching voltage | 250 V AC |
Limiting continuous current | 3 A (5 A up to 35°C at 24 V DC) |
Maximum inrush current | 5 A |
Min. switching current | 1 mA |
Interrupting rating (ohmic load) max. | 72 W (at 24 V DC) |
Switching capacity | - |
Connection method | Screw connection |
Stripping length | 8 mm |
Conductor cross section rigid | 0.2 mm² ... 2.5 mm² |
Conductor cross section flexible | 0.2 mm² ... 2.5 mm² |
Conductor cross section AWG | 24 ... 14 |
Tightening torque | 0.5 Nm |
Width | 6.2 mm |
Height | 80 mm |
depth | 61 mm |
Color | green (RAL 6021) |
Flammability rating according to UL 94 | - |
Degree of protection (Relay) | - |
Degree of protection (Relay base) | - |
Ambient temperature (operation) | -20 °C ... 50 °C |
Ambient temperature (storage/transport) | -20 °C ... 70 °C |
Temperature | - |
Humidity | - |
Vibration | - |
EMC | - |
Enclosure | - |
Low Voltage Directive | - |
Electromagnetic compatibility | - |
Standards/regulations | IEC 60947-5-1 |
Mounting Type | DIN rail mounting |
Mounting position | any |
Contact Connection type | - |
Output fuse | - |
Degree of protection (Installation location) | - |
Get A Quote for Phoenix Contact Terminal Width 6.2 mm Relay DEK-REL- 24/1/S part no: 2964131 at unbeatable prices. Detailed Specifications of DEK-REL- 24/1/S, 2964131 feature Relay Module type and DEK Product family a versatile solution for Palm switch applications. This relay module features a mechanical service life of approx. 2x 107 cycles, ensuring durability and reliability. With a maximum power dissipation of 0.16 W, it operates efficiently at a nominal input voltage of 24 V AC/DC, within an input voltage range of 19.2 V AC/DC ... 26.4 V AC/DC (20 °C). The module has a typical input current of 6.5 mA at UN, with a response time of 5 ms and a release time of 15 ms. It is equipped with a Bridge rectifier; Bridge rectifier for protection and includes 1 N/O contact made from Screw connection Connection method. Match Your Needs with a Quote for your requirement of Phoenix Contact Terminal Width 6.2 mm Relay. Our pricing and support are unrivaled, especially when compared to other Distributors.
