Phoenix PLC-RPT- 24UC/21-21/MS Relay Module
The Phoenix PLC-RPT- 24UC/21-21/MS Relay Module (Part No: 2910520 ) offers a 24 V AC/DC nominal input voltage UN, 20.6 V AC/DC ... 33.6 V AC/DC (20 Β°C) input voltage range, polarized Drive, 3 ms ... 15 ms typical response time. Manufactured by Phoenix under the Phoenix Relay Module category, this model belongs to the Phoenix PLC Series.
| Brand | Phoenix Contact |
| Product Type | Relay Module |
| Model Number | PLC-RPT- 24UC/21-21/MS |
Phoenix PLC-RPT- 24UC/21-21/MS Relay Module β Technical Specifications
| Specification | Value |
|---|---|
| Product type | Relay Module |
| Product family | PLC-INTERFACE |
| Application | Palm switch |
| Mechanical service life | 5x 106 cycles |
| Insulation | Safe isolation, reinforced insulation |
| Overvoltage category | III |
| Pollution degree | 2 |
| Maximum power dissipation for nominal condition | 0.44 W |
| Test voltage (Winding/contact) | 4 kVrms (50 Hz, 1 min.) |
| Test voltage (Changeover contact/changeover contact) | 2.5 kVrms (50 Hz, 1 min.) |
| Rated surge voltage | 6 kV |
| Nominal input voltage UN | 24 V AC/DC |
| Input voltage range | 20.6 V AC/DC ... 33.6 V AC/DC (20 Β°C) |
| Drive and function | monostable |
| Drive (polarity) | polarized |
| Typical input current at UN | 18 mA |
| Typical response time | 3 ms ... 15 ms |
| Typical release time | - |
| Protective circuit | Bridge rectifier; Bridge rectifier |
| Operating voltage display | Yellow LED |
| Contact switching type | 2 changeover contacts |
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC (The separating plate PLC-ATP should be installed for voltages larger than 250 V (L1, L2, L3) between identical terminal blocks in adjacent modules. Potential bridging is then carried out with FBST 8-PLC... or ...FBST 500...) |
| Limiting continuous current | 6 A |
| Maximum inrush current | 12 A (20 ms) |
| Min. switching current | 10 mA (12 V) |
| Interrupting rating (ohmic load) max. | 192 W (24 V DC) |
| Switching capacity | 1 A (24 V, DC13) |
| Connection method | Push-in connection |
| Stripping length | 10 mm |
| Conductor cross section rigid | 0.14 mmΒ² ... 2.5 mmΒ² |
| Conductor cross section flexible | 0.14 mmΒ² ... 2.5 mmΒ² |
| Conductor cross section AWG | 26 ... 14 |
| Tightening torque | - |
| Width | 14 mm |
| Height | 80 mm |
| depth | 104 mm |
| Color | gray (RAL 7042) |
| Flammability rating according to UL 94 | V0 (Housing) |
| Degree of protection (Relay) | RT II |
| Degree of protection (Relay base) | IP20 |
| Ambient temperature (operation) | -40 Β°C ... 60 Β°C |
| Ambient temperature (storage/transport) | -40 Β°C ... 85 Β°C |
| Temperature | D |
| Humidity | A |
| Vibration | B/C |
| EMC | B |
| Enclosure | Required protection according to the Rules shall be provided upon installation on board |
| Low Voltage Directive | Conformance with Low Voltage Directive |
| Electromagnetic compatibility | Conformance with EMC directive |
| Standards/regulations | IEC 60947-5-1 |
| Mounting Type | DIN rail mounting |
| Mounting position | any |
| Contact Connection type | - |
| Output fuse | - |
| Degree of protection (Installation location) | β₯ IP54 |
Get A Quote for Phoenix Relay with Bridge Rectifier PLC-RPT- 24UC/21-21/MS part no: 2910520 at the best price. Here are the brief Technical Specifications of PLC-RPT- 24UC/21-21/MS, 2910520 are Relay Module type and PLC-INTERFACE Product family a versatile solution for Palm switch applications. This relay module features a mechanical service life of 5x 106 cycles, ensuring durability and reliability. With a maximum power dissipation of 0.44 W, it operates efficiently at a nominal input voltage of 24 V AC/DC, within an input voltage range of 20.6 V AC/DC ... 33.6 V AC/DC (20 Β°C). The module has a typical input current of 18 mA at UN, with a response time of 3 ms ... 15 ms and a release time of -. It is equipped with a Bridge rectifier; Bridge rectifier for protection and includes 2 changeover contacts made from Push-in connection Connection method. It's Time to get a Quote for your requirement of Phoenix Relay with Bridge Rectifier. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
