Phoenix FL SWITCH 2506-2SFP PN Industrial Ethernet Switches
The Phoenix FL SWITCH 2506-2SFP PN Power Supply (Part No: 1089135 ) offers a Push-in spring connection method, 100/1000 Mbps (full duplex) transmission speed, 19.2 V DC ... 32 V DC supply voltage range, IP20 degree of protection. Manufactured by Phoenix under the Phoenix Industrial Ethernet Switches category, this model belongs to the Phoenix FL Series.
| Brand | Phoenix Contact |
| Product Type | Industrial Ethernet switches |
| Model Number | FL SWITCH 2506-2SFP PN |
Phoenix FL SWITCH 2506-2SFP PN Industrial Ethernet Switches
| Specification | Value |
|---|---|
| Width | 128 mm |
| Height | 113 mm |
| Depth | 67 mm |
| Housing material | Stainless steel 1.4301 |
| Mounting type | DIN rail mounting |
| Connection method | Push-in spring connection |
| Transmission speed | 100/1000 Mbps (full duplex) |
| Transmission length | up to 80 km (depending on the SFP module used) |
| Signal LEDs | Data receive, link status |
| No. of channels | 2 (SFP ports) |
| Product type | Switch |
| MTTF | 357.82 Years (SN 29500 standard, temperature 25°C, operating cycle 21%) |
| Article revision | 3 |
| Supply voltage (DC) | 24 V DC (redundant) |
| Supply voltage range | 19.2 V DC ... 32 V DC |
| Power supply connection | Via COMBICON, max. conductor cross section 2.5 mm² |
| Max. current consumption | 350 mA (US = min, Tamb = max) |
| Typical current consumption | 260 mA (at US = 24 V DC and 25 °C ambient temperature) |
| Degree of protection | IP20 |
| Ambient temperature (operation) | -40 °C ... 70 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Permissible humidity (operation) | 10 % ... 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 10 % ... 95 % (non-condensing) |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Noise emission | EN 61000-6-4 |
| Status display | LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (link/activity and speed), PROFINET status LEDs (BF, SF) |
| Shock (operation) | 30g (EN 60068-2-27) |
| Vibration (operation) | in acc. with IEC 60068-2-6: 5g, 150 Hz |
Ask for the Pricing of Phoenix Contact 6 ports Managed Switch FL SWITCH 2506-2SFP PN part no: 1089135 at unbeatable prices. Detailed Specifications of FL SWITCH 2506-2SFP PN, 1089135 feature Stainless steel 1.4301 housing material, ensuring long-lasting performance in demanding environments. It supports easy installation with a standard DIN rail mounting making it ideal for streamlined setup in control panels. The connection method is via reliable Push-in spring connection, providing secure and stable connectivity. With a transmission speed of 100/1000 Mbps (full duplex) it ensures fast and efficient data communication across networks. The relay supports a transmission length of up to up to 80 km (depending on the SFP module used) making it versatile for various industrial settings. It features 2 (SFP ports). Now's the Time to Secure a Quote for your requirement of Phoenix Contact 6 ports Managed Switch. We're committed to offering more favorable pricing and more responsive support than other Traders.
