FL SWITCH 1104NT-SFP: 1343023 - Phoenix 1 SFP port Ethernet Switch
Technical Specifications of Phoenix 1 SFP port Narrow Ethernet Switch FL SWITCH 1104NT-SFP 1343023:
| Spec | Value |
|---|---|
| Mounting type | DIN rail mounting |
| Connection method | Push-in spring connection |
| No. of channels | 1 (SFP port) |
| Status display | LEDs: US, link and activity per port |
FL SWITCH 1104NT-SFP: 1343023 - Phoenix 1 SFP port Ethernet Switch
| Specification | Value |
|---|---|
| Width | 22.5 mm |
| Height | 123 mm |
| Depth | 90 mm |
| Housing material | Polycarbonate fiber reinforced |
| Mounting type | DIN rail mounting |
| Connection method | Push-in spring connection |
| Transmission speed | 100/1000 Mbps (full duplex) |
| Transmission length | up to 40 km (Depending on the fiber/SFP module used) |
| Signal LEDs | Data receive, link status |
| No. of channels | 1 (SFP port) |
| Product type | Switch |
| MTTF | 87.5 Years (MIL-HDBK-217F standard, temperature 25°C, operating cycle 100%) |
| Article revision | 1 |
| Supply voltage (DC) | 24 V |
| Supply voltage range | 9 V DC ... 32 V DC |
| Power supply connection | Via COMBICON, max. conductor cross section 2.5 mm² |
| Max. current consumption | 425 mA (at 9 V DC) |
| Typical current consumption | 47 mA (at 24 V DC) |
| Degree of protection | IP30 |
| Ambient temperature (operation) | -40 °C ... 75 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Permissible humidity (operation) | 5 % ... 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 5 % ... 95 % (non-condensing) |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Noise emission | EN 61000-6-4:2007 + A1:2011 |
| Status display | LEDs: US, link and activity per port |
| Shock (operation) | 30g (EN 60068-2-27) |
| Vibration (operation) | in acc. with IEC 60068-2-6: 5g, 150 Hz |
Ask for the Pricing of Phoenix 1 SFP port Narrow Ethernet Switch FL SWITCH 1104NT-SFP part no: 1343023 at unbeatable prices. Detailed Specifications of FL SWITCH 1104NT-SFP, 1343023 feature Polycarbonate fiber reinforced housing material, ensuring long-lasting performance in demanding environments. It supports easy installation with a standard DIN rail mounting making it ideal for streamlined setup in control panels. The connection method is via reliable Push-in spring connection, providing secure and stable connectivity. With a transmission speed of 100/1000 Mbps (full duplex) it ensures fast and efficient data communication across networks. The relay supports a transmission length of up to up to 40 km (Depending on the fiber/SFP module used) making it versatile for various industrial settings. It features 1 (SFP port). Now's the Time to Secure a Quote for your requirement of Phoenix 1 SFP port Narrow Ethernet Switch. We're committed to offering more favorable pricing and more responsive support than other Traders.
