FL SWITCH 2608 PN: 1106616 - Phoenix 8 M12 ports Ethernet Switch
Technical Specifications of Phoenix 8 M12 ports Industrial Ethernet Switch FL SWITCH 2608 PN 1106616:
| Spec | Value |
|---|---|
| Mounting type | Wall mounting |
| Connection method | M12 connector (L-coded) |
| No. of channels | 8 (M12 ports) |
| Status display | LEDs: US1, US2 (power supply), Fail, 2 LEDs per Ethernet port (Link/Activity and Speed) |
FL SWITCH 2608 PN: 1106616 - Phoenix 8 M12 ports Ethernet Switch
| Specification | Value |
|---|---|
| Width | 60 mm |
| Height | 226 mm |
| Depth | 46 mm |
| Housing material | Zinc die-cast |
| Mounting type | Wall mounting |
| Connection method | M12 connector (L-coded) |
| Transmission speed | 10/100 Mbps |
| Transmission length | 100 m (per segment) |
| Signal LEDs | Data receive, link status |
| No. of channels | 8 (M12 ports) |
| Product type | Switch |
| MTTF | 461.15 Years (SN 29500 standard, temperature 25°C, operating cycle 21%) |
| Article revision | 2 |
| Supply voltage (DC) | 24 V DC (redundant) |
| Supply voltage range | 9 V DC ... 57 V DC |
| Power supply connection | |
| Max. current consumption | 0.52 A (US = min, Tamb = max) |
| Typical current consumption | 180 mA (at US = 24 V DC and 25 °C ambient temperature) |
| Degree of protection | IP65 |
| Ambient temperature (operation) | -40 °C ... 70 °C |
| Ambient temperature (storage/transport) | -40 °C ... 85 °C |
| Permissible humidity (operation) | 5 % ... 95 % |
| Permissible humidity (storage/transport) | 5 % ... 95 % |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Noise emission | EN 61000-6-3 |
| Status display | LEDs: US1, US2 (power supply), Fail, 2 LEDs per Ethernet port (Link/Activity and Speed) |
| Shock (operation) | 30g (EN 60068-2-27) |
| Vibration (operation) | in acc. with IEC 60068-2-6: 5g, 150 Hz |
Obtain a Quote for Phoenix 8 M12 ports Industrial Ethernet Switch FL SWITCH 2608 PN part no: 1106616 at economical prices. Specifications Overview for FL SWITCH 2608 PN, 1106616 reveals Zinc die-cast housing material, ensuring long-lasting performance in demanding environments. It supports easy installation with a standard Wall mounting making it ideal for streamlined setup in control panels. The connection method is via reliable M12 connector (L-coded), providing secure and stable connectivity. With a transmission speed of 10/100 Mbps it ensures fast and efficient data communication across networks. The relay supports a transmission length of up to 100 m (per segment) making it versatile for various industrial settings. It features 8 (M12 ports). Take the First Step with a Quote for your requirement of Phoenix 8 M12 ports Industrial Ethernet Switch. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
