Phoenix EMG 17-REL/KSR- 48/21-21-LC AU Relay Module
The Phoenix EMG 17-REL/KSR- 48/21-21-LC AU Relay Module (Part No: 2941332 ) offers a 48 V AC/DC nominal input voltage UN, 38.4 V AC/DC ... 52.8 V AC/DC (20 Β°C) input voltage range, polarized Drive, 8 ms typical response time. Manufactured by Phoenix under the Phoenix Relay Module category, this model belongs to the Phoenix PLC Series.
| Brand | Phoenix Contact |
| Product Type | Relay Module |
| Model Number | EMG 17-REL/KSR- 48/21-21-LC AU |
Phoenix EMG 17-REL/KSR- 48/21-21-LC AU Relay Module β Technical Specifications
| Specification | Value |
|---|---|
| Product type | Relay Module |
| Product family | EMG |
| Application | Universal |
| Mechanical service life | approx. 2x 107 cycles |
| Insulation | Safe isolation, reinforced insulation |
| Overvoltage category | III |
| Pollution degree | 2 |
| Maximum power dissipation for nominal condition | 0.48 W |
| Test voltage (Winding/contact) | 4 kV AC (50 Hz, 1 min., winding/contact) |
| Test voltage (Changeover contact/changeover contact) | - |
| Rated surge voltage | 6 kV |
| Nominal input voltage UN | 48 V AC/DC |
| Input voltage range | 38.4 V AC/DC ... 52.8 V AC/DC (20 Β°C) |
| Drive and function | monostable |
| Drive (polarity) | polarized |
| Typical input current at UN | 10 mA |
| Typical response time | 8 ms |
| Typical release time | 10 ms |
| Protective circuit | Bridge rectifier; Bridge rectifier |
| Operating voltage display | Yellow LED |
| Contact switching type | 2 changeover contacts |
| Type of switch contact | Single contact |
| Contact material | AgNi, hard gold-plated |
| Maximum switching voltage | 250 V AC/DC |
| Limiting continuous current | 5 A |
| Maximum inrush current | 6 A |
| Min. switching current | - |
| Interrupting rating (ohmic load) max. | 120 W (at 24 V DC) |
| Switching capacity | - |
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Conductor cross section rigid | 0.2 mmΒ² ... 4 mmΒ² |
| Conductor cross section flexible | 0.2 mmΒ² ... 2.5 mmΒ² |
| Conductor cross section AWG | 24 ... 12 |
| Tightening torque | - |
| Width | 17.5 mm |
| Height | 75 mm |
| depth | 62.5 mm |
| Color | green (RAL 6021) |
| Flammability rating according to UL 94 | - |
| Degree of protection (Relay) | - |
| Degree of protection (Relay base) | - |
| Ambient temperature (operation) | -20 Β°C ... 40 Β°C |
| Ambient temperature (storage/transport) | -20 Β°C ... 70 Β°C |
| Temperature | - |
| Humidity | - |
| Vibration | - |
| EMC | - |
| Enclosure | - |
| Low Voltage Directive | - |
| Electromagnetic compatibility | - |
| Standards/regulations | EN 61810-1 |
| Mounting Type | DIN rail mounting |
| Mounting position | any |
| Contact Connection type | - |
| Output fuse | - |
| Degree of protection (Installation location) | - |
Talk to Our Engineer for Phoenix 48V Relay Module EMG 17-REL/KSR- 48/21-21-LC AU part no: 2941332 with exclusive offers. Core System Specifications of EMG 17-REL/KSR- 48/21-21-LC AU, 2941332 are Relay Module type and EMG Product family a versatile solution for Universal applications. This relay module features a mechanical service life of approx. 2x 107 cycles, ensuring durability and reliability. With a maximum power dissipation of 0.48 W, it operates efficiently at a nominal input voltage of 48 V AC/DC, within an input voltage range of 38.4 V AC/DC ... 52.8 V AC/DC (20 Β°C). The module has a typical input current of 10 mA at UN, with a response time of 8 ms and a release time of 10 ms. It is equipped with a Bridge rectifier; Bridge rectifier for protection and includes 2 changeover contacts made from Screw connection Connection method. Don't Miss Out on a Quote for your requirement of Phoenix 48V Relay Module. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
