Phoenix Contact RBO 5-T-F E - 3059595 - Bolt connection terminal block
Technical Specifications of Bolt connection terminal block RBO 5-T-F E 3059595
| Brand | Phoenix Contact |
| Product Type | Terminal Block |
| Product | RBO 5-T-F E |
Phoenix Contact Bolt connection terminal block RBO 5-T-F E, 3059595 Technical Specifications
| Specification | Value |
|---|---|
| Product type | Bolt connection terminal block |
| DIN rail/fixing support | Test passed |
| Number of connections | 2 |
| Number of rows | 1 |
| Potentials | 1 |
| Overvoltage category | III |
| Degree of pollution | 2 |
| Rated surge voltage | 6 kV |
| Number of connections per level | 2 |
| Nominal cross section | 10 mm² |
| Stripping length | The stripping length depends on the specification provided by the cable lug manufacturer. |
| Connection in acc. with standard | IEC 6094771 |
| Nominal current | 50 A |
| Maximum load current | 50 A (with 10 mm² conductor cross section) |
| Nominal voltage | 800 V |
| Width | 20.75 mm |
| End cover width | 10 mm |
| Height | 39.7 mm |
| Color | dark gray |
| Flammability rating according to UL 94 | V2 |
| Insulating material group | I |
| Insulating material | PA |
| Relative insulation material temperature index (Elec., UL 746 B) | 125 °C |
| Test voltage setpoint | 2 kV |
| Result | Test passed |
| Requirement temperature-rise test | Increase in temperature ⤠45 K |
| Open side panel | Yes |
| Time of exposure | 30 s |
| Ambient temperature (operation) | 60 °C ... 110 °C (Operating temperature range incl. selfheating; for max. shortterm operating temperature, see RTI Elec.) |
| Ambient temperature (storage/transport) | 25 °C ... 60 °C (for a short time, not exceeding 24 h, 60 °C to +70 °C) |
| Ambient temperature (assembly) | 5 °C ... 70 °C |
| Ambient temperature (actuation) | 5 °C ... 70 °C |
| Permissible humidity (operation) | 20 % ... 90 % |
| Permissible humidity (storage/transport) | 30 % ... 70 % |
| Mounting type | direct screw connection |
| Screw thread | M5 |
| Tightening torque | 2 ... 2.2 Nm |
| Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)) | 125 °C |
| Specification | DIN EN 50155 (VDE 0115200):200803 |
| Spectrum | Long life test category 2, bogiemounted |
| Frequency | f1 = 5 Hz to f2 = 250 Hz |
| ASD level | 6.12 (m/s²)²/Hz |
| Acceleration | 30g |
| Test duration per axis | 5 h |
| Test directions | X, Y and Zaxis (pos. and neg.) |
| Pulse shape | Semisinusoidal |
| Shock duration | 18 ms |
| Number of shocks per direction | 3 |
| Pitch | 13 mm |
| Tightening torque disconnect slide | 1.2 ... 1.4 Nm |
| Cross section | 1 mm² ... 6 mm² |
| Cross section range AWG | 20 ... 10 (converted acc. to IEC) |
| Hole diameter | 5.3 mm |
| Bolt diameter | 5 mm |
| Identification color of ring cable lugs : red | 1 mm² |
| Identification color of ring cable lugs : blue | 2.5 mm² |
| Identification color of ring cable lugs : yellow | 6 mm² |
| Short-time withstand current 10 mm² | 1.2 kA |
