Phoenix Contact PSR-MC31-2SDO-1DO-24DC-SC - 1015520 - Safety relays
Technical Specifications of Safety relays PSR-MC31-2SDO-1DO-24DC-SC 1015520
| Brand | Phoenix Contact |
| Product Type | Safety Relays |
| Product | PSR-MC31-2SDO-1DO-24DC-SC |
Phoenix Contact Safety relays PSR-MC31-2SDO-1DO-24DC-SC, 1015520 Technical Specifications
| Specification | Value |
|---|---|
| Note on application | Only for industrial use |
| Product type | Safety relays |
| Product family | PSRmini |
| Application | Emergency stop |
| Control | 1 and 2 channel |
| Overvoltage category | III |
| Degree of pollution | 2 |
| Typical response time | < 200 ms (automatic start) |
| Typ. starting time with Us | < 200 ms (with Us when controlled via A1) |
| Restart time | < 250 ms (Boot time) |
| Recovery time | 250 ms (following demand of the safety function) |
| Maximum power dissipation for nominal condition | 3.1 W (UB = 30 V , IL1 = IL2 = 2.4 A) |
| Nominal operating mode | 100% operating factor |
| Rated insulation voltage | 50 V AC |
| Rated surge voltage/insulation | See section βInsulation coordinationβ |
| Description of the input | safety-related |
| Number of inputs | 1 |
| Input voltage range "1" signal | 11 V DC ... 30 V DC |
| Inrush current | max. 4.8 A (Ξt = 10 ms) |
| Filter time | max. 1.5 ms (Test pulse width of low test pulses) |
| Max. permissible overall conductor resistance | 150 Ξ© |
| Protective circuit | Suppressor diode |
| Current consumption | 7 mA |
| Output description | PNP |
| Number of outputs | 1 |
| Switching frequency | 1 Hz (Resistive, inductive, capacitive) |
| pluggable | yes |
| Connection method | Screw connection |
| Conductor cross section rigid | 0.2 mmΒ² ... 2.5 mmΒ² |
| Conductor cross section flexible | 0.2 mmΒ² ... 2.5 mmΒ² |
| Conductor cross-section AWG | 24 ... 12 |
| Stripping length | 7 mm |
| Screw thread | M3 |
| Status display | 3 x LED (green) |
| Operating voltage display | 1 x LED (green) |
| Width | 12.5 mm |
| Height | 112.2 mm |
| Depth | 114.5 mm |
| Color (Housing) | yellow (RAL 1018) |
| Housing material | PA |
| Category | 4 |
| Performance level (PL) | e |
| Safety Integrity Level (SIL) | 3 |
| Degree of protection | IP20 |
| Min. degree of protection of inst. location | IP54 |
| Ambient temperature (operation) | -40 Β°C ... 70 Β°C (observe derating) |
| Ambient temperature (storage/transport) | -40 Β°C ... 70 Β°C |
| Maximum altitude | β€ 2000 m (Above sea level) |
| Max. permissible humidity (storage/transport) | 75 % (on average, 85% infrequently, non-condensing) |
| Max. permissible relative humidity (operation) | 75 % (on average, 85% infrequently, non-condensing) |
| Shock | 30g |
| Vibration (operation) | 10 Hz ... 150 Hz, 5g |
| Identification | CE-compliant |
| Mounting type | DIN rail mounting |
| Mounting position | vertical or horizontal |
| Rated control circuit supply voltage US | 24 V DC -20 % / +25 % (provide external protection) |
| Rated control supply current IS | typ. 54 mA (No load) |
| Power consumption at US | typ. 1.3 W |
| Input voltage range "0" signal | 0 V DC ... 5 V DC |
| Input current range "0" signal | 0 mA ... 2 mA |
| Concurrence | β |
| Tightening torque | 0.5 Nm ... 0.6 Nm |
| Assembly note | See derating curve |
| Maximum inrush current | 500 mA (Ξt = 1 ms at Us) |
| Designation | A1/A2 |
| Voltage | approx. 22 V DC (Us - 2 V) |
| Current | max. 100 mA |
| Response time | < 10 ms (Take the extension of the response time into consideration if you switch several devices in sequence.) |
| Ohmic load | min. 12 Ξ© |
| Short-circuit protection | Yes |
| Cable length | 100 m |
| Error indication | 1 x LED (red) |
| Protection class | II (EN 50178) |
| Output voltage | β₯ 23 V DC (Us - 1 V) |
| Leakage current | max. 1 mA (in the safe state) |
| Max. capacitive load | max. 10 Β΅F (2.4 A load) |
| Max. inductive load | max. 1 H |
| Limitation of the voltage induced on circuit interruption | max. 50 V |
| Output current | max. 2.4 A |
| Min. load current | 2 mA |
| Output voltage when switched off | < 5 V DC (in the safe state) |
| Test pulses | < 1 ms (Test pulse width of low test pulses) |
