Phoenix Contact PSR-FTB/1.5/11.5 - 2904476 - Filter terminal block
Technical Specifications of Filter terminal block PSR-FTB/1.5/11.5 2904476
| Brand | Phoenix Contact |
| Product Type | Safety Relays |
| Product | PSR-FTB/1.5/11.5 |
Phoenix Contact Filter terminal block PSR-FTB/1.5/11.5, 2904476 Technical Specifications
| Specification | Value |
|---|---|
| Note on application | Only for industrial use |
| Product type | Filter terminal block |
| Overvoltage category | II |
| Maximum power dissipation for nominal condition | 3.6 W |
| Rated insulation voltage | 50 V |
| Protective circuit | Surge protection |
| Limiting continuous current | max. 2 A (in total for OUT1 + OUT2) |
| Connection method | Push-in connection |
| Conductor cross section rigid | 0.14 mmΒ² ... 2.5 mmΒ² |
| Conductor cross section flexible | 0.14 mmΒ² ... 2.5 mmΒ² |
| Stripping length | 8 mm |
| Width | 6.2 mm |
| Height | 94 mm |
| Depth | 80 mm |
| Degree of protection | IP20 |
| Ambient temperature (operation) | -25 Β°C ... 55 Β°C |
| Ambient temperature (storage/transport) | -25 Β°C ... 70 Β°C |
| Mounting position | Vertical (horizontal DIN rail) |
| Assembly note | in rows with zero spacing |
| Nominal input voltage UN | 24 V DC Β±20 % (Control voltage UST right/left) |
| Typical input current at UN | max. 15 mA |
| Color | green (RAL 6021) |
| Rated surge voltage | 1.5 kV |
| Area of application | Functional safety |
| Operating mode | 100% operating factor |
| Insulation | Basic insulation |
| Pollution degree | 2 |
| Nominal output voltage | 24 V DC Β±20 % (Control voltage UST right/left) |
| Nominal output voltage range | 19.2 V DC ... 28.8 V DC (Control voltage UST right/left) |
| Load current range | 65 mA |
| Conductor cross section AWG | 26 ... 14 |
