Home Products Proximity Sensor Pepperl Fuchs NCB1,5-8GM25-N0-V1 Pepperl Fuchs NCB1,5-8GM25-N0-V1 Proximity Sensor The Pepperl Fuchs NCB1,5-8GM25-N0-V1 Proximity Sensor offers a 1.5 mm operating distance, 2-wire, Normally closed (NC), output, and flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
Brand Pepperl Fuchs Product Type Proximity Sensor Model Number NCB1,5-8GM25-N0-V1
Pepperl Fuchs NCB1,5-8GM25-N0-V1 Proximity Sensor β Technical Specifications Specification Value Switching function Normally closed (NC) Output type 2-wire Rated operating distance 1.5 mm Installation flush Assured operating distance 0 ... 1.215 mm Switching frequency 0 ... 2000 Hz Hysteresis 1 ... 10 % typ. 3 % Reverse polarity protection reverse polarity protected Short-circuit protection yes Switching state indicator Multihole-LED, yellow Ambient temperature -25 ... 100 Β°C (-13 ... 212 Β°F) Storage temperature -40 ... 100 Β°C (-40 ... 212 Β°F) Connection type Connector plug Housing material Stainless steel 1.4305 / AISI 303 Sensing face LCP Degree of protection IP67
