Pepperl Fuchs Inductive Proximity Sensors
NCB2-V3-N0
NCB2-V3-N0 Technical Specifications:
| Switching function | Normally closed (NC) |
| Output type | NAMUR |
| Rated operating distance | 2 mm |
| Installation | flush |
| Assured operating distance | 0 … 1.62 mm |
| Reduction factor rAl | 0.3 |
| Reduction factor rCu | 0.2 |
| Reduction factor r304 | 0.7 |
| Output type | 2-wire |
| Nominal voltage | 8.2 V (Ri approx. 1 kΩ) |
| Switching frequency | 0 … 2000 Hz |
| Hysteresis | typ. 3% |
| Switching state indicator | LED, yellow |
| Current consumption- Measuring plate not detected | ≥ 3 mA |
| Current consumption – Measuring plate detected | ≤ 1 mA |
| Safety Integrity Level (SIL) | SIL 2 |
| MTTFd | 2180 a |
| Mission Time (TM) | 20 a |
| Diagnostic Coverage (DC) | 0 % |
| Standard conformity – NAMUR | EN 60947-5-6:2000 IEC 60947-5-6:1999 |
| Standard conformity – Standards | EN 60947-5-2:2007 EN 60947-5-2/A1:2012 IEC 60947-5-2:2007 IEC 60947-5-2 AMD 1:2012 |
| IECEx approval – Equipment protection level Ga | IECEx PTB 11.0021X |
| IECEx approval – Equipment protection level Gb | IECEx PTB 11.0021X |
| IECEx approval – Equipment protection level Da | IECEx PTB 11.0021X |
| IECEx approval – Equipment protection level Mb | IECEx PTB 11.0021X |
| ATEX approval – Equipment protection level Ga | PTB 00 ATEX 2032 X |
| ATEX approval – Equipment protection level Gb | PTB 00 ATEX 2032 X |
| ATEX approval – Equipment protection level Da | PTB 00 ATEX 2032 X |
| EAC conformity | TR CU 012/2011 |
| UL approval – Ordinary Location | E87056 |
| UL approval – Hazardous Location | E501628 |
| UL approval – Control drawing | 116-0451 |
| CCC approval Hazardous Location | 2020322315002302 |
| NEPSI certificate | GYJ16.1394X |
| ANZEx | 19.3001X |
| Ambient temperature | -25 … 100 °C (-13 … 212 °F) |
| Connection type | cable |
| Housing material | PBT |
| Sensing face | PBT |
| Degree of protection | IP67 |
| Cable diameter | 2.6 mm ± 0.2 mm |
| Cable Bending radius | > 10 x cable diameter |
| Cable Material | PVC |
| Cable Core cross-section | 0.14 mm2 |
| Cable Length | 130 mm |
Product Documentation: NCB2-V3-N0
Related Products: NCB2-V3-N0
NBN8-12GM50-E2
Inductive Proximity Sensor, Sensor diameter: M12, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Sensor length: 50mm, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: DC 5-36V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN8-18GM50-E2-V1
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN8-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 8 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB5-18GM40-Z0
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 5 mm, Switching function: Normally open (NO), Output type: Two-wire, Installation: Flush, Switching frequency: 0 … 500 Hz, Output type: 2-wire, Type of voltage: DC, Connection type: 2 m PVC cable, Operating voltage: 5 … 60 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBB5-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 5 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1950 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB5-18GM50-E2
Inductive Proximity Sensor, Sensor diameter: M18, Rated operating distance: 5 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 1950 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GK50-E2
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 1200 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 10 … 30 V, Housing material: PBT, Degree of protection: IP68 / IP69K.
NBN4-12GM40-E0
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GM40-E2
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBN4-12GM40-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Non-flush, Switching frequency: 0 … 2650 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB4-12GM30-E2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 2550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB4-12GM30-E2-V3
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: PNP, Installation: Flush, Switching frequency: 0 … 500 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug M8 x 1 , 3-pin, Operating voltage: 10 … 30 V, Housing material: Brass with nickel-plating, Degree of protection: IP67.
NBB4-12GM30-E3-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally closed (NC), Output type: PNP, Installation: Flush, Switching frequency: 0 … 2550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB4-12GM50-A2-V1
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Complementary, Output type: PNP, Installation: Flush, Switching frequency: 0 … 2550 Hz, Output type: 4-wire, Type of voltage: DC, Connection type: Connector plug, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68.
NBB4-12GM50-E0
Inductive Proximity Sensor, Sensor diameter: M12, Rated operating distance: 4 mm, Switching function: Normally open (NO), Output type: NPN, Installation: Flush, Switching frequency: 0 … 2550 Hz, Output type: 3-wire, Type of voltage: DC, Connection type: Cable, Operating voltage: 5 … 36 V, Housing material: Brass with white bronze coating, Degree of protection: IP68, Cable length: 2 m.
The NCB2-V3-N0 is an inductive proximity sensor manufactured by Pepperl Fuchs. It has a normally closed (NC) switching function and a NAMUR output type. This sensor has a rated operating distance of 2mm and is designed for flush installation. It has a reduction factor for different metals and operates on a nominal voltage of 8.2V.
The switching frequency ranges from 0 to 2000 Hz, and the hysteresis is approximately 3%. It has an LED yellow switching state indicator and a safety integrity level (SIL) of 2. The NCB2-V3-N0 sensor conforms to various standards such as EN 60947-5-6:2000 and has multiple approvals, including IECEx and ATEX. It has a cable connection and a PBT housing material with an IP67 degree of protection.
You can check the P&F 2mm series with the Cable type.
