Home Products Proximity Sensor Pepperl Fuchs NBB20-U1K-N0 Pepperl Fuchs NBB20-U1K-N0 Proximity Sensor The Pepperl Fuchs NBB20-U1K-N0 Proximity Sensor offers a 20 mm operating distance, 2-wire, Normally closed (NC), output, and flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
Brand Pepperl Fuchs Product Type Proximity Sensor Model Number NBB20-U1K-N0
Pepperl Fuchs NBB20-U1K-N0 Proximity Sensor – Technical Specifications Specification Value Switching function Normally closed (NC) Output type 2-wire Rated operating distance 20 mm Installation flush Assured operating distance 0 ... 16.2 mm Switching frequency 0 ... 250 Hz Hysteresis 1 ... 15 % typ. 5 % Reverse polarity protection reverse polarity protected Short-circuit protection yes Switching state indicator LED, yellow Ambient temperature -25 ... 100 °C (-13 ... 212 °F) Storage temperature -40 ... 100 °C (-40 ... 212 °F) Connection type screw terminals Housing material PA Sensing face PA Degree of protection IP66 / IP68 / IP69K Mass 225 g
