Home Products Proximity Sensor Pepperl Fuchs NBB1-4GM22-E2-0,3M-V3 Pepperl Fuchs NBB1-4GM22-E2-0,3M-V3 Proximity Sensor The Pepperl Fuchs NBB1-4GM22-E2-0,3M-V3 Proximity Sensor offers a 1 mm operating distance, 3-wire, PNP, Normally open (NO), output, and flush installation. Manufactured by Pepperl Fuchs under the P&F Proximity Sensor category.
Brand Pepperl Fuchs Product Type Proximity Sensor Model Number NBB1-4GM22-E2-0,3M-V3
Pepperl Fuchs NBB1-4GM22-E2-0,3M-V3 Proximity Sensor β Technical Specifications Specification Value Switching function Normally open (NO) Output type 3-wire, PNP Rated operating distance 1 mm Installation flush Assured operating distance 0 ... 0.81 mm Switching frequency 0 ... 700 Hz Hysteresis typ. 5% Reverse polarity protection reverse polarity protected Short-circuit protection pulsing Switching state indicator LED, yellow Ambient temperature -25 ... 70 Β°C (-13 ... 158 Β°F) Connection type fixed cable with plug Housing material Stainless steel 1.4305 / AISI 303 Sensing face PC Degree of protection IP67 Mass 14 g
