Panasonic MSMF042L1A1 Servo Motor
The Panasonic MSMF042L1A1 Servo Motor offers a Low inertia type, 60 mm sq. dimension, Round shaft, and 1.27 rated torque. Manufactured by Panasonic under the Panasonic Servo Motor category, this model belongs to the MSMF Series.
| Brand | Panasonic |
| Product Type | Servo Motor |
| Model Number | MSMF042L1A1 |
Panasonic MSMF042L1A1 Servo Motor – Technical Specifications
| Specification | Value |
|---|---|
| Type | Low inertia |
| Protection Class | IP67 |
| Flange sq. Dimension | 60 mm sq. |
| Flange sq. Dimension (Unit:mm) | 60 |
| Motor Lead-out Configuration | Connector |
| Motor Encoder Connector | Connector |
| Power Supply Capacity (kVA) | 0.9 |
| Voltage Specifications (V) | 100 |
| Rated Output (W) | 400 |
| Rated Current (A (rms)) | 4.6 |
| Shaft | Round |
| Rated Torque (N ⋅ m) | 1.27 |
| Continuous Stall Torque (N ⋅ m) | 1.27 |
| Momentary Max. Peak Torque (N ⋅ m) | 3.82 |
| Max. Current (A (o-p)) | 10.2 |
| Rated Rotational Speed (r/min) | 3000 |
| Rated Rotational Max. Speed (r/min) | 6000 |
| Moment of Inertia of Rotor ( x10-4 kg ⋅ m²) | 0.27 |
Obtain a Quote for Panasonic Low Inertia, 100 V Servo Motors, MSMF042L1A1 at economical prices. Specifications Overview for MSMF042L1A1 reveals Round, 4.6, 400 & 1.27. It also includes 60 mm sq., 60 & Connector. Take the First Step with a Quote for your requirement of Panasonic Low Inertia, 100 V Servo Motors. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
