Panasonic MSMF022L1U2MServo Motor
The Panasonic MSMF022L1U2M Servo Motor offers a Low inertia type, 60 mm sq. dimension, Key-way, center tap shaft, and 0.64 rated torque. Manufactured by Panasonic under the Panasonic Servo Motor category, this model belongs to the MSMF Series.
| Brand | Panasonic |
| Product Type | Servo Motor |
| Model Number | MSMF022L1U2M |
Panasonic MSMF022L1U2M Servo Motor – Technical Specifications
| Specification | Value |
|---|---|
| Type | Low inertia |
| Protection Class | IP65 |
| Flange sq. Dimension | 60 mm sq. |
| Flange sq. Dimension (Unit:mm) | 60 |
| Motor Lead-out Configuration | Lead wire |
| Motor Encoder Connector | Lead wire |
| Power Supply Capacity (kVA) | 0.5 |
| Voltage Specifications (V) | 200 |
| Rated Output (W) | 200 |
| Rated Current (A (rms)) | 1.5 |
| Shaft | Key-way, center tap |
| Rated Torque (N ⋅ m) | 0.64 |
| Continuous Stall Torque (N ⋅ m) | 0.64 |
| Momentary Max. Peak Torque (N ⋅ m) | 1.91 |
| Max. Current (A (o-p)) | 6.5 |
| Rated Rotational Speed (r/min) | 3000 |
| Rated Rotational Max. Speed (r/min) | 6000 |
| Moment of Inertia of Rotor ( x10-4 kg ⋅ m²) | 0.14 |
Ask for the Pricing of Panasonic Minas A6 Servo Motor MSMF022L1U2M at unbeatable prices. Detailed Specifications of MSMF022L1U2M feature Key-way, center tap, 1.5, 0.64, 200. Moreover, it features 60 mm sq., 60, Lead wire. Now's the Time to Secure a Quote for your requirement of Panasonic Minas A6 Servo Motor. We're committed to offering more favorable pricing and more responsive support than other Traders.
