Panasonic MSMF011L1A1Servo Motor
The Panasonic MSMF011L1A1 Servo Motor offers a Low inertia type, 38 mm sq. dimension, Round shaft, and 0.32 rated torque. Manufactured by Panasonic under the Panasonic Servo Motor category, this model belongs to the MSMF Series.
| Brand | Panasonic |
| Product Type | Servo Motor |
| Model Number | MSMF011L1A1 |
Panasonic MSMF011L1A1Servo Motor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Low inertia |
| Protection Class | IP67 |
| Flange sq. Dimension | 38 mm sq. |
| Flange sq. Dimension (Unit:mm) | 38 |
| Motor Lead-out Configuration | Connector |
| Motor Encoder Connector | Connector |
| Power Supply Capacity (kVA) | 0.4 |
| Voltage Specifications (V) | 100 |
| Rated Output (W) | 100 |
| Rated Current (A (rms)) | 1.6 |
| Shaft | Round |
| Rated Torque (N β m) | 0.32 |
| Continuous Stall Torque (N β m) | 0.32 |
| Momentary Max. Peak Torque (N β m) | 0.95 |
| Max. Current (A (o-p)) | 6.9 |
| Rated Rotational Speed (r/min) | 3000 |
| Rated Rotational Max. Speed (r/min) | 6000 |
| Moment of Inertia of Rotor ( x10-4 kg β mΒ²) | 0.048 |
Give Us a Call for Panasonic 24 Volt DC Servo Motor MSMF011L1A1 at the lowest pricing. The MSMF011L1A1 includes a power range from 50W to 22kW, DC 24V input power supply, and a 23-bit Absolute/Incremental encoder. It delivers a frequency response of 3.2 kHz for rapid response. For further information, download the MSMF011L1A1 datasheet or refer to the MSMF011L1A1 manual. Donβt miss the best MSMF011L1A1 price in Maharashtra, Gujarat, Delhi NCR, Tamil Nadu, Karnataka, Telangana, Andhra Pradesh, West Bengal, Odisha, Jharkhand, Madhya Pradesh, Rajasthan, and Punjab.
