Omron S8VK-G24024 Power Supply
Omron S8VK-G24024 SMPS is a 240 W switch mode power supply designed to provide 24 VDC with 10 A rated output current. It accepts single-phase 85 to 264 VAC or 90 to 350 VDC input at 50/60 Hz and uses DIN rail mounting with screw terminals and terminal blocks for panel installation and electrical connections. Efficiency is specified at 92%. A green output indicator provides operating status, and the enclosure carries an IP20 protection rating. The 24 VDC output and 10 A capacity define this model within the S8VK-G family. Within the S8VK-G Series, the S8VK-G24024 provides a 240 W, 24 VDC configuration. Compare other 240 W power supplies from Omron industrial automation.

| Brand | Omron |
| Product | Power Supply |
| Model Number | S8VK-G24024 |
Omron S8VK-G24024 Power Supply - Technical Specifications
| Specification | Value |
|---|---|
| Power rating | 240 W |
| Output voltage | 24 VDC |
| Rated output current | 10 A |
| Terminal type | Screw Terminal |
| Mounting method | DIN rail |
| Connection | Terminal blocks |
| Efficiency | 92% |
| Rated input voltage | Single-phase, 85 to 264 VAC, 90 to 350 VDC |
| Rated input current | 2.4 A typ. (at 115 VAC input) 1.3 A typ. (at 230 VAC input) |
| Input Leakage current | 0.23 mA typ. (at 115 VAC input) 0.33 mA typ. (at 230 VAC input) |
| Input Frequency | 50/60 Hz |
| Output indicator | Yes (LED: Green) |
| Output voltage variable range | ?10% to 15% (with V. ADJ) |
| Start-up time | 250 ms typ. (at 115 VAC input) 250 ms typ. (at 230 VAC input) |
| Hold time | 44 ms typ. (at 115 VAC input) 44 ms typ. (at 230 VAC input) |
| Vibration resistance | 10 to 55 Hz, maximum 5 G, 0.42 mm single amplitude for 2 h each in X, Y, and Z directions |
| Shock resistance | 150 m/s2, in each 6 directions 3 times |
| Ambient temperature (Operating) | ?40 to 70°C |
| Ambient temperature (Storage) | ?40 to 85°C |
| Ambient humidity (OperatingStorage) | 95% max. (Storage humidity: 95% max.) |
| Cooling fan | No |
| Degree of protection | IP20 by EN/IEC 60529 |
| Weight | 900 g max. |
The Omron S8VK-G24024 Power Supply provides 240 W rated power with a 24 VDC output and 10 A rated current. It accepts single-phase 85 to 264 VAC or 90 to 350 VDC input at 50/60 Hz and uses DIN rail mounting with screw terminals and terminal blocks for installation and wiring. Efficiency is specified at 92%, and a green indicator provides output-status information. The enclosure carries an IP20 protection rating. These values define the electrical and installation requirements for matching the supply to connected equipment. The load should require 24 VDC, and combined current demand should remain within the rated 10 A output. The incoming source must remain within the specified input range, while mounting space and terminal access should suit the panel layout. Input compatibility and output compatibility describe different sides of the power supply, so they should be checked separately. When comparing related models, output voltage should be checked first, followed by required current, rated power, mounting format, and connection type. Models with the same 24 VDC, 10 A electrical ratings can still belong to different product families. For comparison, the Omron S8VK-WB24024 provides 240 W rated power with a 24 VDC output and 10 A rated current, allowing comparison between product-family configurations.
