Omron S8VK-G03024 Power Supply
Omron S8VK-G03024 SMPS is a 30 W switch mode power supply designed to provide 24 VDC with 1.3 A rated output current. It accepts 85 to 264 VAC or 90 to 350 VDC input at 50/60 Hz and uses DIN track mounting with rod terminals and terminal blocks. Efficiency is specified at 86% with 100 VAC input and 87% with 200 VAC input. A green output indicator provides operating status, and the enclosure carries an IP20 protection rating. The 24 VDC output and 1.3 A capacity define this model within the S8VK-G family. Within the S8VK-G Series, the S8VK-G03024 provides a 30 W, 24 VDC configuration. Compare other 24 VDC industrial SMPS models from Omron industrial controls.

| Brand | Omron |
| Product | Power Supply |
| Model Number | S8VK-G03024 |
Omron S8VK-G03024 Power Supply – Technical Specifications
| Specification | Value |
|---|---|
| Power rating | 30 W |
| Output voltage | 24 VDC |
| Rated output current | 1.3 A |
| Terminal type | Rod terminal |
| Mounting method | DIN track mounting |
| Construction | Covered type. |
| Connection | Terminal blocks |
| Efficiency | 86% typ. (at 100 VAC input)87% typ. (at 200 VAC input) |
| Rated input voltage | 100 to 240 VAC |
| Rated input current | 0.65 A typ. (at 100 VAC input)0.4 A typ. (at 200 VAC input) |
| Input Leakage current | 0.5 mA max. (at 100 VAC input)1.0 mA max. (at 200 VAC input) |
| Input Frequency | 50/60Hz (47 to 450 Hz) |
| Allowable input voltage variable range | 85 to 264 VAC (Single-phase)90 to 350 VDC |
| Output indicator | Yes (color: green, lighting from 80 to 90% or more of rated voltage) |
| Output voltage variable range | -10 to +15% With V.ADJ |
| Maximum peak current | 1.56 A |
| Start-up time | 600 ms typ. (at 100 VAC input)500 ms typ. (at 200 VAC input) |
| Hold time | 20 MS type. (at 100 VAC input)110 MS type. (at 200 VAC input) |
| Vibration resistance | 10 to 55 Hz, 0.375 mm Single amplitude in every 3 directions for 2 hours |
| Shock resistance | 150 m/s2, in each 6 directions 3 times |
| Ambient temperature (Operating) | -40 to 70 ? (with no freezing or condensation) |
| Ambient temperature (Storage) | -40 to 85 ? (with no freezing or condensation) |
| Cooling fan | Cooling fan No |
| Degree of protection | IP20 by EN / IEC 60529 |
| Weight (Main) | 195 g max. |
The Omron S8VK-G03024 Power Supply provides 30 W rated power with a 24 VDC output and 1.3 A rated current. It accepts 85 to 264 VAC or 90 to 350 VDC input at 50/60 Hz and uses DIN track mounting with rod terminals and terminal blocks for installation and wiring. Efficiency is specified at 86% with 100 VAC input and 87% with 200 VAC input, and a green indicator provides output-status information. The enclosure carries an IP20 protection rating. These values define the electrical and installation requirements for matching the supply to connected equipment. The load should require 24 VDC, and combined current demand should remain within the rated 1.3 A output. The incoming source must remain within the specified input range, while mounting space and terminal access should suit the panel layout. Input compatibility and output compatibility describe different sides of the power supply, so they should be checked separately. When comparing related S8VK-G models, output voltage should be checked first, followed by required current, rated power, mounting format, and connection type. A model with another output voltage should not be treated as a direct substitute based on wattage alone. For comparison, the Omron S8VK-G01524 provides 15 W rated power with a 24 VDC output and 0.65 A rated current, showing a lower-capacity option in the same voltage class.
