Omron S8FS-C20024J Power Supply
The Omron S8FS-C20024J Power Supply offers 200 W power rating, 24 VDC output voltage, and 8.8A rated current. This dependable SMPS Power Supply is designed for Direct Mounting and includes Screw Terminal for safe and reliable wiring connections and 50/60 Hz frequency, it ensures steady DC performance even in unstable input conditions. Manufactured by Omron, part of the Omron Power Supply family of Switch Mode Power Supplies, available under the Omron S8FS-C Series.
| Brand | Omron |
| Product Type | SMPS |
| Model Number | S8FS-C20024J |
Omron S8FS-C20024J Power Supply - Technical Specifications
| Specification | Value |
|---|---|
| Power rating | 200 W |
| Output voltage | 24 VDC |
| Connection | Terminal blocks |
| Terminal type | Screw Terminal |
| Mounting | Direct Mounting |
| Efficiency | 88% typ. (at 115 VAC input) 88% typ. (at 230 VAC input) |
| Rated input voltage | Single phase 90 to 132 VAC , Single phase 180 to 264 VAC , 254 to 373 VDC |
| Input Frequency | 50/60 Hz |
| Rated input current | 4.0 A typ. (at 115 VAC input) 2.3 A typ. (at 230 VAC input) |
| Input Leakage current | 0.40 mA max. (at 115 VAC input) 0.75 mA max. (at 230 VAC input) |
| Rated output current | 8.8A |
| Output voltage variable range | β10% to 10% (with V. ADJ) |
| Start-up time | 580 ms max. (at 115 VAC input) 550 ms max. (at 230 VAC input) |
| Hold time | 38 ms typ. (at 115 VAC input) 45 ms typ. (at 230 VAC input) |
| Output indicator | Yes (LED: Green) |
| Vibration resistance | 10 to 55 Hz, 0.375-mm half amplitude for 2 h each in X, Y, and Z directions 10 to 500 Hz, 0.26-mm half amplitude for 1 h each in X, Y, and Z directions |
| Shock resistance | 150 m/s2, 3 times each in Β±X, Β±Y, Β±Z directions |
| Ambient temperature (Operating) | β20 to 50Β°C |
| Ambient temperature (Storage) | β40 to 85Β°C |
| Ambient humidity (OperatingStorage) | 20% to 90% (Storage humidity: 10% to 95%) |
| Cooling fan | No |
| Weight | 700 g max. |
The Omron S8FS-C20024J is frequently assessed alongside related units in the Omron Switch Mode Power Supply range, as these SMPS models share comparable wiring behaviour, thermal characteristics, load endurance, and panel integration features. Engineers often evaluate related models such as Omron S8FS-C35012D (350 W, 12 VDC, 29 A, Direct Mounting), Omron S8FS-C05005J (50 W, 5 VDC, 10 A, DIN rail), and Omron S8FS-C03524D (35 W, 24 VDC, 1.5 A, DIN rail) when configuring power rails for PLC racks, servo drives, motion assemblies, and distributed I/O terminals. Comparing specifications like power rating, output voltage behaviour, continuous output current, and mounting orientation helps maintain predictable voltage delivery across machinery with dynamic load patterns. The S8FS-C20024J fits smoothly into conveyors, dosing modules, electrical frames, and compact control panels where a dependable Omron SMPS Power Supply is required. These related SMPS variants also support unified wiring layouts, easier spare handling, and consistent power distribution across multi-panel automation systems.
