Omron S8FS-C35024 Power Supply
Omron S8FS-C35024 SMPS is a 350 W switch mode power supply configured to provide 24 VDC with a rated output current of 14.6 A. It uses single-phase input, direct mounting, and screw terminals for fixed panel installation. The metal-frame unit has a stated efficiency of 88% and supports 100 to 240 VAC rated input, with allowable ranges of 90 to 264 VAC and 254 to 373 VDC. Its enclosure measures 50 mm wide, 112.5 mm high, and 212 mm deep, with the terminal block facing upward. Within the S8FS-C Series, the S8FS-C35024 provides a direct-mount 350 W, 24 VDC configuration. Compare other 350W 24V power supplies from Omron control systems.

| Brand | Omron |
| Product | Power Supply |
| Model Number | S8FS-C35024 |
Omron S8FS-C35024 Power Supply – Technical Specifications
| Specification | Value |
|---|---|
| Power rating | 350W |
| Output voltage | 24V |
| Rated output current | 14.6A |
| Terminal type | Screw |
| Phase | Single |
| Number of output branches | 1 |
| Allowable supply voltage DC | 254-373 V |
| Mounting method | Direct mounting |
| Type | Metal frame |
| Efficiency | 88% |
| Temperature range | -20-60? |
| Rated supply voltage at AC 50 Hz | 100-240V |
| Height | 50mm |
| Width | 112.5mm |
| Depth | 212mm |
| Features | Terminal block facing upward |
| Allowable supply voltage AC | 90-264 V |
The Omron S8FS-C35024 Power Supply provides 350 W rated power with a 24 VDC output and 14.6 A rated current. It uses single-phase input, direct mounting, and screw terminals for fixed panel installation. Rated input voltage is 100 to 240 VAC, while allowable ranges extend from 90 to 264 VAC and 254 to 373 VDC. The metal-frame unit has a stated efficiency of 88%. Its enclosure measures 50 mm wide, 112.5 mm high, and 212 mm deep, with the terminal block facing upward. These specifications position the model in a higher-capacity 24 VDC class where current demand, panel space, enclosure depth, incoming supply, and conductor clearance should be assessed together.
The connected equipment should require 24 VDC and keep combined current demand within the 14.6 A rating. Direct mounting requires an appropriate panel surface, while the 212 mm depth affects enclosure fit and the upward-facing terminal block affects wiring clearance. A strong capacity comparison keeps output voltage and mounting method aligned while changing available power and current only slightly. For a 300 W direct-mount supply that also provides 24 VDC but with 14 A rated current, compare the Omron S8FS-G30024C-500.
